- Page 1 BDCOM S2952P Hardware Installation Manual...
-
Page 2: Table Of Contents
2.3.3 Cabinet Configuration......................6 2.3.4 Power Requirements......................7 2.4 Installation Tools and Device......................7 Chapter 3 Installing the BDCOM S2952P Switch..................8 3.1 Installation Flow of BDCOM S2952P.....................8 3.2 Installing the Machine Box of the Switch..................8 3.2.1 Installing the Machine Box on the Desk................8 3.2.2 Installing the Machine Box on the Cabinet................9... - Page 3 Table of Contents Chapter 4 Maintaining Switch........................14 4.1 Opening the Machine Box......................14 4.2 Closing the Machine Box.......................15 Chapter 5 Hardware Fault Analysis......................17 5.1 Fault Separation..........................17 5.1.1 Faults Relative with Power and Cooling System............17 5.1.2 Faults Relative with Port, Cable and Connection............17 5.2 Indicator Description........................
-
Page 4: Chapter 1 Bdcom S2952P Introduction
Console port A rate of 9600bps, RJ45 interface Besides, BDCOM S2952P has a grounding column, an AC power socket, a power on-off at its back and a DC power socket. Figure 1- 1 Front template of the BDCOM S2952P switch... -
Page 5: Bdcom S2952P Systematic Characteristic Parameters
Gigabit Ethernet RJ45 port port Figure 1- 2 Back template of the BDCOM S2952P switch Table 1- 3 Parts at the back template of the BDCOM S2952P switch Abbrev. Name Description DC55V (recommended) (current sharing with POWER DC power supply Grounding column The grounding must be fine. -
Page 6: Rohs Description
BDCOM S2952P Hardware Installation Manual Power characteristics Input voltage: AC100～240V, Input frequency: 47～63Hz Input current: 2A (MAX) Input voltage: DC44-57V Input current: 15A(MAX) Output voltage: 12VDC Output current: 4A(MAX) Output voltage: 53.5VDC Output current: 7.11A(MAX) Power consumption 400W 1.3 ROHS Description... -
Page 7: Chapter 2 Installation Preparation
Similar to other electronic products, the semiconductor chip easily gets damaged if you power on or off abruptly and frequently. To restart up the switch of BDCOM S2952P, you have to open the power on-off after the power is cut down for three to five seconds. -
Page 8: Safety Principles For Live Working
BDCOM S2952P Hardware Installation Manual Read the installation guide carefully before you operate the system. Only professionals are allowed to install or replace the switch. Pull out the AC power socket and close the direct-current power before ... -
Page 9: Electrostatic Discharge Damage Prevention
BDCOM S2952P Hardware Installation Manual D. Seek for medical help, or judge the loss and seek for available help. 2.2.4 Electrostatic Discharge Damage Prevention Electrostatic discharge may damage devices and circuits. Improper treatment may cause the switch to malfunction completely or discontinuously. -
Page 10: Power Requirements
2.4 Installation Tools and Device The tools and devices to install the BDCOM S2952P switch are not provided by the BDCOM S2952P switch. You yourself need to prepare them. The following are the... -
Page 11: Chapter 3 Installing The Bdcom S2952P Switch
Installing the machine box on the desk Installing the machine box on the cabinet 3.2.1 Installing the Machine Box on the Desk The BDCOM S2952P switch can be directly put on the smooth and safe desk. Note: - 8 -... -
Page 12: Installing The Machine Box On The Cabinet
The rate of the console port is 9600bps. It has a standard RJ45 plug. After you connect the console port to the serial port of PC through a console cable, you can configure and monitor the switch of BDCOM S2952P by running the terminal emulation software, such as super Windows terminal. The cable is provided according to the host. -
Page 13: Connecting 10Ge Ethernet Sfp+ Ports
Otherwise, the single-pass problem will arise on the super terminal. The cable is used to connect the console port of the BDCOM S2952P switch and the outside console terminal device. One end is RJ45 port and the other end is 9-hole plug(DB9). -
Page 14: Connecting Gigabit Ethernet Tx Ports
BDCOM S2952P Hardware Installation Manual Figure 3-4 Connecting the Ethernet terminal to 10GE SFP+ ports Caution: the device shown in the above figure does not represent the material BDCOM S2952P 3.3.2 Connecting Gigabit Ethernet TX Ports The BDCOM S2952P switch has 48 10/100/1000Base-T ports and 48 corresponding indicators 1~48. - Page 15 BDCOM S2952P Hardware Installation Manual Figure 3-5 Gigabit SFP ports connect to other Ethernet terminal devices The POE total power of BDCOM S2952P has reached to 370W. The first 24 ports (1~24) and the latter 24 ports (25~48) share the total power in average.
-
Page 16: Checking After Installation
BDCOM S2952P Hardware Installation Manual Sending/receiving the paraphase of the TP3- data 3 3.4 Checking after Installation Before electrically starting up the switch, perform the following checkups after the switch is installed: If the switch is installed on the cabinet, check whether the installation point ... -
Page 17: Chapter 4 Maintaining Switch
BDCOM S2952P Hardware Installation Manual Chapter 4 Maintaining Switch Caution: Before opening the machine box, make sure that you have released the static you carried and then turn off the power on-off of the switch. Before operating any step in Appendix B, read the section “Safety Advice”. -
Page 18: Closing The Machine Box
BDCOM S2952P Hardware Installation Manual When the cover is opened, put it aside. The mainboard of the system appears. Note: After taking off the cover, put it horizontally and avoid it to be crushed or collided. Otherwise, the machine box is hard to install. - Page 19 BDCOM S2952P Hardware Installation Manual Nail the bolt and screw it tightly with the screwdriver. Reinstall the switch on the cabinet or the desk. Reconnect all cables of the switch. - 16 -...
-
Page 20: Chapter 5 Hardware Fault Analysis
9600 bps, eight data bits, no sum check bit, one stop bit and no traffic control. 5.2 Indicator Description The following table shows the indicators of the BDCOM S2952P switch and their description: - 17 -... - Page 21 BDCOM S2952P Hardware Installation Manual Abbrev. Name Description When the switch is powered on, the Power indicator indicator is on. When the indicator is always on, the system is being started up. System indicator When the indicator flickers, the system works well.
