Chapter 1 S2928 Introduction

The section describes the characteristics and parameters of S2928 and gives an
overview of S2928.

1.1 Appearance Description for Standard Configuration

The built-in ports of S2928 are: 20 gigabit-Ethernet TX port, 4 10G Ethernet SFP+
ports, 4 gigabit combo TX/ SFP+ ports, 1 Console port. See table 1-1.
Port
Gigabit-Ethernet
port
Gigabit combo TX/SFP
port
10G Ethernet
port
Console port
No. Abbrev.
1 SYS
Table 1-1 Attributes of the built-in port
10/100/1000M
TX
auto-identification,
indicators
TX port: 10/100/1000M auto-adaptation, MDI/MDIX
auto-identification,
indicators
Optical port: SFP port, support the gigabit optical
module, LINK/ACT indicators
optical SFP+ port, support the 10G optical module, LINK/ACT
indicators
A rate of 9600bps, mini USB interface
Figure 1-1 Front template of the S2928 switch
Table 1-2 Parts at the front template of the S2928 switch
Name
System indicator
S2928 Hardware Installation Manual
Attribute
auto-adaptation,
UTP (RJ45) port,
UTP(RJ45) port,
Description
If the indicator is always on, the
system is normally started up.
If the indicator flickers, the system
MDI/MDIX
LINK/ACT
LINK/ACT
