Specifications
S.NO
Component
Specifications
Wattage: 4500W ± 3%,
1
Heater (Electrical Model)
Resistance Across The Terminals:11Ω ± 10%.
Wiring Diagram - Gas Dryer (FFLG4033QW)
82
