5.2.1 Upper Cabinet / Drum Heater
POS. NO
1
3
4
6
8
9
12
13
14
15 #
17
18
19
19A
20
21
22
22*
22A
23
24
25
26 #
27
29
30
31
32
33 #
35
36 #
38
39
41
42
44
46
DESCRIPTION
Panel, left side, white
Panel, top
Panel, rear, dryer, stainless
Clip, ball, steel, flat nut
Limiter, thermal, heater
Panel, motor access, washed
Bearing, drum support
Bracket, bearing support
Screw, bracket mtg. 10-16B x 1.375, cr/sq drive
Housing, heater, gas
Baffle, heater shield
Screw, 10-16AB x 0.375
Cover, moisture sensor, assembly
Clip, end cap mtg, U-type
Glide, flat, dryer
Drum, LC GALV GD
Panel, Front, weld asmy LC Dr
Plug, light hole
Pin, panel locator
Seal, felt, lower
Seal, felt, upper
Door Catch, upper
Switch, door
Lint Trap
Screw, quadrex head, 10-14 x 1.00, vane mtg. special
Vane, straight
Screw, 10-16AB x 0.625
Shaft, drum support, ball hitch
Thermostat, safety
Screw, pan head, 8-18AB x 0.375
Thermal Limiter
Panel, right side, white
Panel, access
Hinge, dryer door
Screw, flat head, 8-18AB x 0.44, quad drive
Gasket, door
Handle, door, white
