14.2 Front Panel Accessibility

Step: 1
Loosen the screws (2) which are fitted to the Base
Assembly Bracket (See Fig.1).
Step: 2
Release the clip that fits in the pocket of the Top Panel (See
Fig.1), and then lift the Front Panel to remove the panel
from the machine (See Fig. 2).
14.3 Motor Control Board
Accessibility
Step: 1
Loosen the screws (2) that fits with the Bracket of the Left
Panel as shown in Fig.1.
