10 OPERATING PARAMETERS
This section provides an overview of all the operating parameters that can be configured individually
on each LEMCOM module (master and secondary). The parameter settings can be defined in the
LEMCOM Manager or by sending SDO commands (see section Messaging).
PARAMETER
Part gripped threshold
Vacuum threshold that generates the "Part
L1
gripped" signal.
Part gripped hysteresis
h1
Vacuum dropout difference leading to the
disappearance of the "Part gripped" signal.
ASC control threshold
Vacuum threshold leading to automatic
L2
deactivation of the suction command (ASC
control system).
Hysteresis at ASC control threshold
h2
Vacuum dropout difference leading to suction
being resumed.
Automatic
Automatic blowing function
blowing
Automatic
Duration of automatic blowing, configurable
blowing duration
from 100 to 9999 ms.
(ms)
ASC
Vacuum control system (Air Saving Control)
Control system assessment function (DIAG
DIAG/E
ECO)
Max. no. of
Maximum number of control system bounces
bounces
before switching over to continuous suction.
DIAG/E
Assessment duration of control system
assessment time
bounce count.
Blue customizable LED
Client LED
Defines the operating mode of the blue LED
on the front of the LEMCOM module.
Operation of Venturi pump in case
communication is lost
Safety feature used to define the status of the
Valve status
vacuum and blowing solenoid valves in case
communication is lost on the field bus (master
module) or the local bus (secondary module).
COVAL – LMCOP-EN-A-1155UM0068
DESCRIPTION
Table 10 – Operating parameters
Operating parameters
COMMENT
Default unit: vacuum percentage (from 0
to 99%)
Other units (inHg/mbar) are available in
LEMCOM Manager.
Triggered automatically as soon as the
suction command is stopped.
Compressed air saving function from 60
to 99%. The control threshold is set by
parameter L2.
DIAG ECO is used to prevent unwanted
triggering of the control in case of vacuum
leakage (porous part).
Switch over to continuous suction as soon
as the number of bounces of the vacuum
solenoid valve exceeds the "Max. no. of
bounces" over the "DIAG/E assessment
time" period.
Refer to section
12.33
for further details
about operating modes.
Refer to section
12.34
for further details
about operating modes.
21/49
