coval PSK100 Series Quick Start Manual

Vacuum managers
For your safety, please read the following before using.
Do not use corrosive or flammable gas or liquid with this product.
1
Please use within the setting pressure range. Do not apply pressure beyond recommended maximum pressure, permanent damage to
2
the pressure sensor may occur.
Do not drop, hit or allow excessive shock. Even if switch body appears undamaged, internal components may be broken and can cause
3
malfunction.
Turn power off before connecting wiring. Wrong wiring or short circuit will damage and / or cause malfunction.
4
Do not use in environment containing steam or oil vapor.
5
This product is not explosion-proof rated. Do not use in atmosphere containing flammable or explosive gases.
6
Wiring for pressure sensor should avoid power source line and high voltage line. If use in the same circuit, noise may cause
7
malfunction.
ESD protection ±4KV.
8
SPECIFICATIONS
Set pressure range
Withstand pressure
Fluid
Power supply voltage
Load current
Internal voltage drop
Current consumption
Sensor type
Output short circuit protection
Setting method
Response time
Repeatability
Hysteresis
Indicator
Enclosure
± 3% F.S. of detected pressure (25°C) at temp. Range of 0~50°C
Temperature characteristic
Operation: 0 ~ 60°C, Storage: -20 ~ 70 °C (No condensation or freezing)
Ambient temp. range
Ambient humidity range
Vibration Total amplitude 1.5mm,10Hz-55Hz-10Hz scan for 1 minute, two hours each direction of X, Y and Z
Shock
Piping method
Electrical connection
Weight
ORDERING INFORMATION
P S K 1 0 0 G 1 8 M 8 N
Pressure Range
Vacuum (- 101.3~0 kPa)
Pressure Port
D6：Ø 6mm Tube
G18：G1/8"(BSPP), M5
M5：M5*0.8
PR-0328C 2022/03 Printing We reserve the right to change the specification without prior notice.
PSK100 M8
- 1 01.3 ~ 0 k Pa
0.6 M Pa
Air, Non-corrosive/Non-flammable gas
10.8 to 30V DC (include ripple voltage)
80mA max.
0.8V
10 mA max.
PNP / NPN
Yes
Adjusting by VR
Approx.1ms
±1% F.S.
3% F.S. max.
Red LED turns ON
IP 40
Operation/Storage: 35 ~ 85% RH ( No condensation)
980m/s (100G), 3 times each in direction of X, Y and Z
2
Push-in tube or thread-in
M8 connection 3-pin (Cable L:150mm)
Approx. 8.3g (with M8, 3-pin male connector)
Output Specifications
- : PNP output
N : NPN output
Wiring Type
With M8, 3Pin male connector
DIMENSIONS
26
10
20
25.4
Hex flat : 10mm
G18:G1/8" (BSPP), M5
22.5
Hex flat : 8mm
M5:M5*0.8
20
29.5
D6 : Ø6mm
CIRCUIT WIRING DIAGRAM
DC(+)
Brown
Red
Black
R
L
Switch
NPN
main
OUT
circuit
Blue DC(–)
Brown DC(+)
Red
Switch
OUT
PNP
main
Black
R
L
circuit
Blue
DC(–)
HOW TO SET PRESSURE
Use the pressure setting trimmer to set "ON" pressure.
Rotate clockwise to increase pressure setpoint .
Rotate counter-clockwise to decrease pressure setpoint .
Use appropriate size screwdriver for the setting trimmers.
Gently turn the screwdriver to make adjustments.
To prevent damage to the pressure setting trimmer,
1
DO NOT force the trimmer when it comes to a stop.
COVAL SAS - Vacuum Components - ZA des Petits Champs - 26120 Montélier - FRANCE - Tel +33 (0)4 75 59 91 91
PSK100 series
150
10.4
CONNECTOR PINOUT
17.3
1
OUTPUT TYPE
DC10.8~30V Hys.≦3% F.S.
H
Setting Pressure
DC10.8~30V
Vacuum
4
(1) Brown(+)
(3) Blue(–)
(4) Black(OUT)
3
Unit:mm
Vacuum Pressure
22
www.coval.com
