Updating Firmware
3
After the final record is received, the Device Server checks the integrity of the
firmware image before programming the new firmware into the flash ROM.
Note: Do not switch off the power supply at this time. A loss of power while
reprogramming will result in a corrupt program image and a
nonfunctional Device Server. This process may take up to 10 minutes
when using the serial method.
4
The following message displays when the firmware upgrade is complete.
5
The Device Server performs a power reset after the firmware has been loaded
Note: You can only update the Device Server's internal Web interface using
TFTP.
Figure C-3: Firmware Upgrade Screen Display
*** NodeSet 2.0 ***
0>DL
02049 lines loaded.
Max Address FFE0
Loading EEPROM ...
Reloading Firmware
.
C-3
