CoBox-Mini100
Test Bed
The CoBox-Mini100 Embedded Integration Kit (part number Mini100-Kit) includes a test
bed (carrier board) that provides serial and network connections to the Device Server. The
test bed contains diagnostic LEDs, a voltage regulator, a power supply circuit, a reset
switch, TTL to RS-232 and RS-232 to TTL hardware conversion.
The test bed allows software engineers to immediately begin developing and testing
software applications for the Device Server, rather than delaying the process until the
hardware interface for their product is complete.
Figure 4-3: CoBox-Mini100 Test Bed
9
6
5
1
CON1
PWR
CON7
CH1
9
6
5
1
CON8
CH2
1
10
1
10
11
1
7
1
CON4
1
8
LED4
Test Bed
LED1
LED2
LED3
LED5
4-5
