5 LED display
SIVS 600-.../IPVS 600-...
LED signalling SIVS 600-...
Switching on
LED green LED red
OFF ON
ON ON
Fast flashing ON
Operation
LED green LED red
ON OFF
Slow flashing OFF
Fast flashing OFF
Fault
LED green LED red
OFF Slow flashing
ON Slow flashing
ON Fast flashing
OFF OFF
Frequencies: Slow appr. 2 Hz, fast appr. 16 Hz
LED signalling IPVS 600-...
The underneath of the IP video server IPVS 600-... has 3 LEDs which display operating statuses and can provide an
indication of possible errors.
LED operating status
OFF
Lights up in green
Flashes green
Lights up in red (briefly)
Lights up in red (continuous)
LED L
Lights up in green
LED T
Lights up in orange
Function
After reset, power on: Device boots to operating status.
The boot area is checked. Software runs in the flash
After a software update, the boot area is recreated.
This can take up to around 3 minutes.
Function
Booting is complete. All OK. Normal status
Display, a connection exists
A software update or reconfiguration process is under way
Function
ERROR, software running only in bootloader. Program memory
defective. (Device defective, possibly new software update or
exchange.)
Variobus address error (error remedy possible on site)
The 15 V power supply (terminal bv, cv) is overloaded. (Error
remedy possible on site)
If supply voltage is definitely connected, the device
is defective. (Exchange)
Function
IPVS 600-... is switched off.
IPVS 600-... is switched on
Access to the IPVS 600-...
Start process running
Error in the device or failed upload
Network connection exists
Active data transmission via the network
