Installing the detector

Selection of the installation site

The controlled area and the e ciency of the security system depends on the
location of the detector.
The device developed only for indoor use.
Location of the CombiProtect depends on the remoteness from the hub and
presence of any obstacles between the devices hindering the radio signal
transmission: walls, inserted oors, large-size objects located within the room.
Check the signal level at the installation location
If the signal level is at one bar, we cannot guarantee stable operation of the
security system. Take all possible measures to improve the quality of the signal!
As a minimum, move the device – even 20 cm shift can signi cantly improve the
quality of reception.
If after moving the device still has a low or unstable signal strength, use a
signal range extender ReX
The direction of the detector lens should be perpendicular to the probable way
of intrusion into the room. The detector microphone should be positioned at the
angle of no more than 90 degrees relative to the window.
.
