Curtain Outdoor Jeweller user manual
Updated October 3, 2024
Curtain Outdoor Jeweller is a wireless curtain-type motion detector with dual
motion detection technology for outdoor and indoor use. The detector has a
horizontal detection angle of 8° and is designed for the perimeter control:
windows, doorways, and other entrances or exits of the guarded facility. It
detects motion at a distance of up to 12 m.
Buy Curtain Outdoor Jeweller
Curtain Outdoor Jeweller communicates with the hub using two secure
protocols. The detector uses
Jeweller
to transmit alarms and events and
Wings
to update the firmware. The communication range in an open space is up to
1,700 m. Pre-installed batteries ensure up to 3 years of autonomous operation.
The list of compatible hubs is
available here
.
You can manage the detector and its settings using iOS, Android, macOS, and
Windows
apps
. The system notifies users of any events via push notifications,
SMS, or calls.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Curtain Outdoor Jeweller and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AJAX Curtain Outdoor Jeweller

Summary of Contents for AJAX Curtain Outdoor Jeweller

  • Page 1 Curtain Outdoor Jeweller user manual Updated October 3, 2024 Curtain Outdoor Jeweller is a wireless curtain-type motion detector with dual motion detection technology for outdoor and indoor use. The detector has a horizontal detection angle of 8° and is designed for the perimeter control: windows, doorways, and other entrances or exits of the guarded facility.

  • Page 2: Functional Elements

    Functional elements Detector 1. LED indicator. 2. Motion detector’s lens. 3. Masking sensor. 4. Power button. Tamper button . It triggers in case of an attempt to detach the detector from the surface or remove it from the mounting panel.
  • Page 3 6. QR code with the device ID. It is used to add the detector to the hub. 7. Slider for adjusting the motion detection distance. 8. SmartBracket mounting panel. To remove the panel, slide it down. 9. Perforated part of the mounting panel. Triggers a tamper in case of any attempt to detach the detector from the surface.

  • Page 4: Operating Principle

    Operating principle 00:00 00:12 Two parallel IR sensors of Curtain Outdoor Jeweller register intrusion upon detecting moving objects with a temperature different from the ambient. When the device detects motion, it additionally performs a radio frequency (RF) scan with a built-in K-band microwave sensor. It helps to eliminate false alarms...
  • Page 5 RF sensor only if both IR sensors register identical signals. If it is disabled, Curtain Outdoor Jeweller runs an RF scan when at least one of the two IR sensors detects thermal radiation.

  • Page 6: Pet Immunity

    Pet immunity When properly installed and configured, Curtain Outdoor Jeweller will not respond to pets up to 1 m (100 cm) in height. We recommend installing the detector at a height of 1 m, adjusting the slider on the detector enclosure to the Pet position, and setting up the Pet immune detection mode in the app.
  • Page 7 Masking is an attempt to block the view of the detector. Curtain Outdoor Jeweller detects the following types of masking: An obstacle in front of the detector’s lens at the distance of up to 5 cm. The maximum distance depends on the material. Painting over the detector’s lenses.

  • Page 8: Adding To The System

    When an alarm is received, the operator at the security company’s monitoring station knows what happened and precisely where to dispatch a rapid response unit. The addressability of Ajax devices allows sending events to PRO Desktop or the CMS, including the device’s type and name, security group, and virtual room.
  • Page 9 The space functionality is available for apps of such versions or later: Ajax Security System 3.0 for iOS; Ajax Security System 3.0 for Android; Ajax PRO: Tool for Engineers 2.0 for iOS; Ajax PRO: Tool for Engineers 2.0 for Android; Ajax PRO Desktop 4.0 for macOS;...
  • Page 10 Curtain Outdoor Jeweller works with only one hub. Once the device is connected to a new hub, it stops sending events to the old one. Adding the detector to a new hub does not automatically remove it from the device list of the old hub.
  • Page 11 Icons The icons in the app display some Curtain Outdoor Jeweller states. To access them: 1. Sign in to the Ajax app 2. Select a space 3. Go to the Devices tab. Icon Meaning Jeweller signal strength displays the signal strength between the hub and the device.
  • Page 12 Learn more States The states include information about the device and its operating settings. You can find the states of Curtain Outdoor Jeweller in the Ajax app: 1. Go to the Devices tab. 2. Select Curtain Outdoor Jeweller from the list.
  • Page 13 You can create a scenario by temperature to control automation devices. Temperature Learn more Curtain Outdoor Jeweller is an outdoor detector, and its temperature is not considered when calculating the average temperature in the room to which the detector is assigned.
  • Page 14 Connection status on the Jeweller channel between the detector and the hub (or the range extender): Online — the detector is connected to the Connection via Jeweller hub (or the range extender). Normal state. Offline — the detector is not connected to the hub (or the range extender).
  • Page 15 The battery charge level of the device. Two states available: Battery low. Battery charge When the batteries need to be replaced, Ajax apps and the security company will receive appropriate notifications. Learn more The status of the detector tamper that responds...
  • Page 16 Disabled — the anti-masking system is disabled. Masking will not be detected. Learn more Displays the selected detection mode: Pet immune. Near. Detection mode Far. Ajax apps Configured in and on the device enclosure. correlation signal Status of the processing feature: Correlation signal processing Enabled.
  • Page 17 (the deactivation setting). The feature is configured in Ajax PRO apps. By timer — the device is automatically disabled by the system when the recovery devices auto timer expires (the deactivation setting).
  • Page 18 raise the alarm even if triggered until the countdown ends. Follower — the detector inherits the delays from Entry/Exit detectors. However, when the Follower is triggered individually, it immediately raises the alarm. Delay when entering (alarm activation delay) is the time the user has to disarm the security system after entering the premises.
  • Page 19 Ajax app 1. Select a space 2. Go to the Devices tab. 3. Select Curtain Outdoor Jeweller from the list. 4. Go to Settings by clicking on the icon. 5. Set the required parameters. 6. Click Back to save the settings.
  • Page 20 The room name is displayed in the text of SMS and notifications in the events feed. Sensitivity level of the motion detector. The choice depends on the type of the object, the presence of probable sources of false alarms, and the specifics of the protected area: Low —...
  • Page 21 When enabled, Curtain Outdoor Jeweller detects masking. Curtain Outdoor Jeweller detects the following types of masking: Obstacles in front of the detector’s lens at a distance of up to 5 cm (depending on the Anti-masking material). Painting over the detector’s lens.
  • Page 22 When this option is enabled, connected If motion detected to the system are activated when motion is detected by Curtain Outdoor Jeweller. sirens When this option is enabled, connected to the system are activated when Curtain Outdoor Jeweller detects masking If masking detected The field is displayed and active if the Anti-...
  • Page 23 Delay when leaving (arming delay) is the time the user has to leave the premises after arming. Learn more When enabled, the detector switches to the armed mode when the system is set to Night Mode. Arm in Night Mode Learn more Delay time when entering in Night Mode.
  • Page 24 Switches the detector to the signal attenuation test mode. Signal attenuation test Learn more Opens the Curtain Outdoor Jeweller user User guide manual in the Ajax app. Allows the user to deactivate the device without removing it from the system.
  • Page 25 Unpairs the detector, disconnects it from the Delete device hub, and deletes its settings. Indication 00:00 00:03 Indication upon pressing the power button Indication Event Lights up green for about 0.5 s. Turning the detector on. Lights up green for about 0.5 s, flashes green 6 Turning on the detector not added to the hub.

  • Page 26: Functionality Testing

    firmware update. Functionality testing The Ajax system offers several types of tests to help choose the correct installation place for the devices. Testing does not start immediately. However, the waiting time does not exceed the duration of one hub–device polling...

  • Page 27: Device Placement

    6. Run the test. Device placement Curtain Outdoor Jeweller is suitable for protecting the area around the guarded facility. It allows you to secure the perimeter, leaving space for free movement inside. The detector can be installed both outdoors and indoors.
  • Page 28 When choosing where to place Curtain Outdoor Jeweller, consider the parameters that affect its operation: Motion detection zone.

  • Page 29: Signal Strength

    The icon in the Devices tab in Ajax apps indicates the signal strength: three bars — excellent signal strength; two bars — good signal strength; one bar — low signal strength, stable operation is not guaranteed;...
  • Page 30 When choosing the installation site, consider the detector’s horizontal viewing angle and the width of the detection zone. Incorrect placement of the detector may cause false alarms.
  • Page 31 Motion detection distance Detection zone width (beam) Up to 12 m 1.68 m Up to 8 m 1.12 m Do not install the detector Nearby any metal objects or mirrors that can cause signal attenuation and screening. Opposite trees or bushes in the detection zone of both IR sensors of the detector.

  • Page 32: Installation

    Installation Before installing Curtain Outdoor Jeweller, ensure that you have chosen the optimal location that complies with the requirements of this manual. Use the Installation template to prepare holes for mounting the device’s SmartBracket or angle mount on the surface.
  • Page 33 The hood replaces the detector’s SmartBracket mounting panel, so you need to remove it before installing the detector with hood. To the angle mount. It allows you to install the detector parallel to the guarded facility’s wall. The detector can be installed to the angle mount with the SmartBracket mounting panel or hood.
  • Page 34 When using a third-party mount, ensure that Curtain Outdoor Jeweller is fixed vertically. Deviation from the vertical axis affects the detection area of the detector. Before installation, set the required detection mode in the detector settings on its enclosure. To install the detector: 1.
  • Page 35 3. Set the Detection mode slider on the device enclosure to the required position. Then, the Detection mode setting in the Ajax app should be set to the value appropriate for the slider position. Installation height Slider position Detection mode 2.4 m...
  • Page 36 If the LED indicator is not activated after installing the detector on SmartBracket, check the tamper status in the Ajax app, the integrity of the fastening, and the tightness of the detector fixation on the panel. You will receive a notification if...

  • Page 37: Maintenance

    Pre-installed batteries provide up to 3 years of the detector’s autonomous operation. When the battery is low, the system will send a corresponding notification to Ajax apps. In case of an alarm, the LED indicator will smoothly light up and go out.
