Table 18. STMicroelectronics Morpho connector on NUCLEO-F072RB,

CN7 odd pins
Pin No.
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
1. Default state of BOOT0 is 0. It can be set to 1 when a jumper is on pin5-7 of CN7.Two unused
jumpers are available on CN11 and CN12 (bottom side of the board).
2. U5V is 5 V power from ST-LINK/V2-1 USB connector and it rises before +5V
3. PA13 and PA14 share with SWD signals connected to ST-LINK/V2-1, it is not recommended to
use them as IO pins if ST-LINK part is not cut.
4. Please refer to
44/55
CN7 even pins
Name Name
PC10 PC11
PC12 PD2
VDD E5V
(1)
BOOT0 GND
- -
- IOREF
PA13 RESET
PA14 +3V3
PA15 +5V
GND GND
PB7 GND
(3)
PC13 VIN
(3)
PC14 -
PC15 PA0
PF0 PA1
PF1 PA4
VBAT PB0
PC1 or
PC2
(4)
PB9
PC0 or
PC3
(4)
PB8
