Embedded ST-LINK/V2-1

The ST-LINK/V2-1 programming and debugging tool is integrated in the STM32 Nucleo
boards.
The ST-LINK/V2-1 makes the STM32 Nucleo boards mbed enabled.
The embedded ST-LINK/V2-1 supports only SWD for STM32 devices. For information about
debugging and programming features refer to
debugger/programmer for STM8 and STM32, User
ST-LINK/V2 features.
The changes versus ST-LINK/V2 version are listed below.
•
New features supported on ST-LINK/V2-1:
–
–
–
–
• Features not supported on ST-LINK/V2-1:
–
–
There are two different ways to use the embedded ST-LINK/V2-1 depending on the jumper
states (see
•
Program/debug the MCU on board
• Program/debug an MCU in an external application board using a cable connected to
SWD connector CN4
Both CN2 jumpers ON
Both CN2 jumpers OFF
USB software re-enumeration
Virtual com port interface on USB
Mass storage interface on USB
USB power management request for more than 100 mA power on USB
SWIM interface
Minimum supported application voltage limited to 3 V
Table 3 and Figure
(Section
Jumper state

Figure 5. Typical configuration

DocID025833 Rev 4
UM1075 - ST-LINK/V2 in-circuit
manual, which describes in detail all the
5):
(Section 5.2.2),
5.2.4).

Table 3. Jumper states

ST-LINK/V2-1 functions enabled for on board programming
ST-LINK/V2-1 functions enabled for external CN4 connector
Hardware layout and configuration
Description
(default)
(SWD supported)
