UM1724
Connect
or No.
CN9
digital
1. Please refer to
Warning:
Connect
or No.
Left connectors
CN6
power
CN8
analog
Table 12. Arduino connectors on NUCLEO-F302R8 (continued)
Pin No. Pin name
8 D7
7 D6
6 D5
5 D4
4 D3
3 D2
2 D1
1 D0
Table 9: Solder bridges
PWM is not supported by D9 on STM32F302 since the timer is
not available on PC7.

Table 13. Arduino connectors on NUCLEO-F334R8

Pin No. Pin name
1 NC
2 IOREF
3 RESET
4 +3V3
5 +5V
6 GND
7 GND
8 VIN
1 A0
2 A1
3 A2
4 A3
5 A4
6 A5
DocID025833 Rev 4
Hardware layout and configuration
MCU pin
PA8 -
PB10 TIM2_CH3
PB4 TIM16_CH1
PB5 -
PB3 TIM2_CH2
PA10 -
PA2 USART2_TX
PA3 USART2_RX
for details.
MCU pin
-
-
NRST
-
-
-
-
-
PA0
PA1
PA4
PB0
(1)
PC1 or PB9 ADC_IN7 (PC1) or I2C1_SDA (PB9)
(1)
PC0 or PB8 ADC_IN6 (PC0) or I2C1_SCL (PB8)
Function
Function
-
3.3V Ref
RESET
3.3V input/output
5V output
Ground
Ground
Power input
ADC1_IN1
ADC1_IN2
ADC2_IN1
ADC1_IN11
37/55
