VLT ® HVAC Drive Design Guide
4.2.5. Ordering Numbers:du/dt Filters
Line supply 3x380 to 3x500 V
Adjustable frequency drive size
380-440 V
15 hp [11 kW]
20 hp [15 kW]
25 hp [18.5 kW]
30 hp [22 kW]
40 hp [30 kW]
50 hp [37 kW]
60 hp [45 kW]
75 hp [55 kW]
100 hp [75 kW]
125 hp [90 kW]
150 hp [110 kW]
200 hp [132 kW]
250 hp [160 kW]
300 hp [200 kW]
350 hp [250 kW]
450 hp [315 kW]
500 hp [355 kW]
550 hp [400 kW]
600 hp [450 kW]
670 hp [500 kW]
750 hp [560 kW]
845 hp [630 kW]
950 hp [710 kW]
1070 hp [800 kW]
1340 hp [1000
Minimum
switching fre-
441-500 V
15 hp [11 kW]
20 hp [15 kW]
25 hp [18.5 kW]
30 hp [22 kW]
40 hp [30 kW]
50 hp [37 kW]
75 hp [55 kW]
100 hp [75 kW]
125 hp [90 kW]
150 hp [110 kW]
200 hp [132 kW]
250 hp [160 kW]
300 hp [200 kW]
350 hp [250 kW]
450 hp [315 kW]
500 hp [355 kW]
550 hp [400 kW]
600 hp [450 kW]
670 hp [500 kW]
750 hp [560 kW]
845 hp [630 kW]
950 hp [710 kW]
1070 hp [800 kW]
1340 hp [1000
kW]
1475 hp [1100
kW] kW]
MG.11.B4.22 - VLT ® is a registered Danfoss trademark.
Maximum out-
Part No. IP 20 Part No. IP 00
put frequency
quency
4 kHz 60 Hz 130B2396
4 kHz 60 Hz 130B2397
4 kHz 60 Hz 130B2397
4 kHz 60 Hz 130B2397
3 kHz 60 Hz 130B2398
3 kHz 60 Hz 130B2398
3 kHz 60 Hz 130B2399
3 kHz 60 Hz 130B2399
3 kHz 60 Hz 130B2400
3 kHz 60 Hz 130B2400
3 kHz 60 Hz 130B2401
3 kHz 60 Hz 130B2401
3 kHz 60 Hz 130B2402
3 kHz 60 Hz 130B2402
3 kHz 60 Hz 130B2277
2 kHz 60 Hz 130B2278
2 kHz 60 Hz 130B2278
2 kHz 60 Hz 130B2278
2 kHz 60 Hz 130B2405
2 kHz 60 Hz 130B2405
2 kHz 60 Hz 130B2407
2 kHz 60 Hz 130B2407
2 kHz 60 Hz 130B2407
2 kHz 60 Hz 130B2407
2 kHz 60 Hz 130B2410
4. How to Order
Rated filter
current at 50
Hz
130B2385 24 A
130B2386 45 A
130B2386 45 A
130B2386 45 A
130B2387 75 A
130B2387 75 A
130B2388 110 A
130B2388 110 A
130B2389 182 A
130B2389 182 A
130B2390 280 A
130B2390 280 A
130B2391 400 A
130B2391 400 A
130B2275 500 A
130B2276 750 A
130B2276 750 A
130B2276 750 A
130B2393 910 A
130B2393 910 A
130B2394 1500 A
130B2394 1500 A
130B2394 1500 A
130B2394 1500 A
130B2395 2300 A
