VLT ® HVAC Drive Design Guide
6. Application Examples
6.1.1. Start/Stop
Terminal 18 = start/stop par. 5-10 [8]
Terminal 27 = No operation par. 5-12 [0]
operation
6.1.2. Pulse Start/Stop
Terminal 18 = start/stop par. 5-10 [9]
start
Terminal 27= Stop par. 5-12 [6]
coast inverse
(Default
Par. 5-10 Digital Input = Start
fault)
Digital Input coast in-
Par. 5-12 =
verse
(default)
Stop inverse
Digital Input
Par. 5-10 =
start
Digital Input Stop in-
Par. 5-12 =
verse
MG.11.B4.22 - VLT ® is a registered Danfoss trademark.
Start
No
(de-
6.1: Terminal 37: Available only with Safe Stop
Function!
Latched
Latched
6.2: Terminal 37: Available only with Safe Stop
Function!
