VLT ® HVAC Drive Design Guide
VLT HVAC
200-240 V
K25-K75
1K1-1K5
2K2
3K0
3K7
5K5
7K5
11K
15K
18K5
22K
30K
37K
45K
380-500 V
K37-1K5
2K2-3K0
4K0-5K5
7K5
11K-15K
18K
22K
30K
37K
45K
55K
75K
90K
5.2: Non-UL fuses 200 V to 500 V
1) Max. fuses - refer to national/international regulations to select an appropriate fuse size.
Max. fuse size
1
10A
1
16A
25A 1
25A 1
35A 1
50A 1
1
63A
63A 1
1
80A
125A 1
125A 1
1
160A
200A 1
1
250A
10A 1
16A 1
1
25A
1
35A
1
63A
63A 1
63A 1
80A 1
100A 1
1
125A
1
160A
1
250A
250A 1
