4. How to Order
4.2.6. Ordering Numbers:du/dt Filters, 525-690 V AC
Line supply 3x525 to 3x690 V
Adjustable frequency drive size
15 hp [11 kW]
20 hp [15 kW]
25 hp [18.5 kW]
30 hp [22 kW]
40 hp [30 kW]
4
50 hp [37 kW]
60 hp [45 kW]
75 hp [55 kW]
100 hp [75 kW]
125 hp [90 kW]
150 hp [110 kW]
200 hp [150 kW]
240 hp [180 kW]
295 hp [220 kW]
350 hp [260 kW]
400 hp [300 kW]
500 hp [375 kW]
600 hp [450 kW]
640 hp [480 kW]
750 hp [560 kW]
900 hp [670 kW]
1100 hp [820 kW]
1300 hp [970 kW]
92
Minimum switch-
ing frequency
525-600 V 690 V
15 hp [11 kW]
20 hp [15 kW]
25 hp [18.5 kW]
30 hp [22 kW]
40 hp [30 kW]
50 hp [37 kW]
60 hp [45 kW]
75 hp [55 kW]
100 hp [75 kW]
125 hp [90 kW]
150 hp [110
kW]
200 hp [132
kW]
250 hp [160
kW]
300 hp [200
kW]
350 hp [250
kW]
450 hp [315
kW]
550 hp [400
kW]
670 hp [500
kW]
750 hp [560
kW]
845 hp [630
kW]
950 hp [710
kW]
1070 hp [800
kW]
1200 hp [900
kW]
1340 hp [1000
kW]
1600 hp [1200
kW]
MG.11.B4.22 - VLT
Maximum out-
Part No. IP 20 Part No. IP 00
put frequency
4 kHz 60 Hz 130B2423
4 kHz 60 Hz 130B2423
4 kHz 60 Hz 130B2423
4 kHz 60 Hz 130B2423
4 kHz 60 Hz 130B2424
4 kHz 60 Hz 130B2424
3 kHz 60 Hz 130B2425
3 kHz 60 Hz 130B2425
3 kHz 60 Hz 130B2426
3 kHz 60 Hz 130B2426
3 kHz 60 Hz 130B2427
3 kHz 60 Hz 130B2427
3 kHz 60 Hz 130B2428
3 kHz 60 Hz 130B2428
3 kHz 60 Hz 130B2429
3 kHz 60 Hz 130B2278
3 kHz 60 Hz 130B2278
2 kHz 60 Hz 130B2239
2 kHz 60 Hz 130B2274
2 kHz 60 Hz 130B2274
2 kHz 60 Hz 130B2430
2 kHz 60 Hz 130B2431
2 kHz 60 Hz 130B2431
2 kHz 60 Hz 130B2431
2 kHz 60 Hz 130B2431
