VLT ® HVAC Drive Design Guide
Ordering number:
Please order your CD containing MCT 10 Set-up software using code number 130B1000.
MCT 10 can also be downloaded from the Danfoss homepage at:
Motion Controls.
MCT 31
The MCT 31 harmonic calculation PC tool enables easy estimation of the harmonic distortion in a
given application. Both the harmonic distortion of Danfoss adjustable frequency drives as well as
non-Danfoss adjustable frequency drives with different additional harmonic reduction devices,
such as Danfoss AHF filters and 12-18-pulse rectifiers, can be calculated.
Ordering number:
Please order your CD containing the MCT 31 PC tool using code number 130B1031.
MCT 31 can also be downloaded from Danfoss on the internet at:
Motion Controls.
5.6. Safety
5.6.1. High Voltage Test
Carry out a high voltage test by short circuiting terminals U, V, W, L
2.15 kV DC for one second between this short circuit and the chassis.
5.6.2. Safety Ground Connection
The adjustable frequency drive has a high leakage current and must be grounded appropriately
for safety reasons according to EN 50178.
MCT 10 Set-up Software
Setting parameters
Copy to and from adjustable frequency drives
Documentation and print-out of parameter settings incl. diagrams
Ext. User Interface
Preventive Maintenance Schedule
Clock settings
Timed Action Programming
Smart Logic Controller Set-up
NOTE
When running high voltage tests of the entire installation, interrupt the mains and
motor connection if the leakage currents are too high.
MG.11.B4.22 - VLT ® is a registered Danfoss trademark.
5. How to Install
, Business Area:
WWW.DANFOSS.COM
, Business Area:
WWW.DANFOSS.COM
, L and L . Energize by max.
