4. How to Order
4.1.2. Type Code String
Description
Product group & VLT Series
Power rating
4
Number of phases
AC line voltage
Enclosure
RFI filter
Brake
Display
Coating PCB
Line option
Adaptation
Adaptation
Software release
Software language
A options
B options
C0 options MCO
C1 options
C option software
D options
4.1: Type code description.
The various options are described further in the
86
Pos Possible choice
1-6 FC 102
8-10 1.5-125 hp [1.1-90 kW] (1K1-90K)
11 Three phases (T)
T 2: 200-240 V AC
11-12 T 4: 380-480 V AC
T 6: 525-600 V AC
E20: IP 20
E21: IP 21/NEMA Type 1
E55: IP 55/NEMA Type 12
13-15
E66: IP 66
P21: IP 21/NEMA Type 1 w/backplate
P55: IP 55/NEMA Type 12 w/backplate
H1: RFI filter class A1/B
16-17 H2: Class A2
H3:RFI filter A1/B (reduced cable length)
X: No brake chopper included
B: Brake chopper included
18
T: Safe Stop
U: Safe + brake
G: Graphical Local Control Panel (GLCP)
19 N: Numeric Local Control Panel (NLCP)
X: No Local Control Panel
X. No coated PCB
20
C: Coated PCB
X: No line power disconnect switch
21
1: With line power disconnect switch (IP55 only)
22 Reserved
23 Reserved
24-27 Current software
28
AX: No options
A0: MCA 101 Profibus DP V1
29-30 A4: MCA 104 DeviceNet
AG: MCA 108 LON works
AJ: MCA 109 BAC Net
BX: No option
BK: MCB 101 General purpose I/O option
31-32
BP: MCB 105 Relay option
BO:MCB 109 Analog I/O option
33-34 CX: No options
35 X: No options
36-37 XX: Standard software
DX: No option
38-39
D0: DC backup
