Table 3. Boot Configuration DIP Switch & Header Settings
Function
BOOT_CONFIG[1]
CBL_PWR_N
FORCED_USB_BOOT

3.7.3 Input Power Selection

The development kit can be powered using either external DC power supply or by using a battery. The
input power source selection is performed by using the connectors and selection switches shown in the
figure and subsections below.
Open-Q 865XR SOM Development Kit User Guide
DIP Switch/Header
S2600-1
S2500-2
J2500

Figure 4. Input Power Selection Locations

3: Open-Q 865XR SOM Development Kit
Description
CPU boot configuration bit
1. Connected to CPU
GPIO27
Controls the auto boot of
the SOM when power is
applied.
For factory mode
programming. Connected
to CPU GPIO132.
Notes
For default boot
configuration, leave open /
OFF. Other boot
configurations not
supported.
Default configuration is
open / OFF. To enable
auto boot of the SOM
when power is applied,
set switch closed / ON.
For Lantronix use only.
Leave open.
19
