3.5

Getting Started

This section explains how to setup the Open-Q 865XR SOM Development Kit and start using it.

3.5.1 Registration

To register the development kit and gain access to the Intrinsyc Technical Document Portal, please visit:
http://tech.intrinsyc.com/account/register.
To proceed with registration, the development kit serial number is required. These serial numbers can be
found on the labels that are present on the SOM and carrier boards. The labels contain the following
information:
• SOM: Serial Number, WIFI MAC address
Carrier: Serial Number
•
Note: Please retain the SOM and carrier board serial numbers for warranty purposes.
Refer to http://tech.intrinsyc.com/account/serialnumber
kit serial number.

3.5.2 Configuration Switch Settings

The default configuration for the system configuration DIP switch S2500 is for all switches to be open or
OFF and Header J2500 is open. For details about other configurations, see section 3.7.2.

3.5.3 Powering Up the Development Kit

The development kit can be powered up by either using a DC power supply or by connecting a battery on
connector J300. Select the desired power source using the switch S300 on the carrier board. The green
LED DS2404 marked "POWER" on the board is the power LED and should glow once the development
kit is powered. To see the debug logs, connect a serial debug cable to the J1500 connector.
To power-up the board, perform the following exact steps below detailed below:
1. At a static-safe workstation, remove the development kit board carefully from the anti-static bag.
2. Connect the Power Adapter to the 12V DC Jack J400 and then press and hold the power button
until you see the company logo appears on the on-board display (~3 seconds).
3. Navigate using the touchscreen on the on-board display.
Open-Q 865XR SOM Development Kit User Guide
3: Open-Q 865XR SOM Development Kit
for more details about locating the development
