Position Feature Description
24 M.2 PCIe Card Connector (on bottom side of Carrier Board)
25 SIM Card Socket for M.2 PCIe (on bottom side of Carrier
Board)
26 Audio Outputs Expansion
27 Audio Inputs Expansion
28 Audio Codec Module (on top side of Carrier Board underneath
Display Adapter)
29 Power Header
30 Coin Cell Holder
31 Open-Q 865XR SOM, WLAN/BT CH0 Antenna Connector
32 Open-Q 865XR SOM, WLAN CH1 Antenna Connector
33 Open-Q 865XR SOM
34 On-Board Quiet Thermistor
35 SOM Current Sense Probe Header(SOM_SYS_PWR)
36 LEDs: (BOOT State / Blue / Green / Red )
37 System Configuration DIP Switch
38 Open-Q LCD Panel
39 SOM Current Sense Probe Header(VPH_PWR)
40 Force USB Boot Header
41 Main Power LED
42 VBUS LED
Open-Q 865XR SOM Development Kit User Guide
3: Open-Q 865XR SOM Development Kit
Reference Designator
J2700
J2701
J1801
J1800
U1600
J700
B300
J3700 (on SOM)
J3800 (on SOM)
RT800
J301
DS2403 / DS2400 /
DS2401 / DS2402
S2500
J901
J2500
DS2407
DS2405
