Audio Inputs Expansion Header J1800 (27); Table 15. Audio Inputs Expansion Header Pinout J1800 - Lantronix Intrinsyc Open-Q 865XR SOM User Manual

GPIO_161_SNS_I3C0_SC
17
L
GPIO_167_SNS_SPI2_CS
19
0_N
GPIO_166_SNS_SPI2_CL
21
K
23 GPIO_122_ALSP_INT_N
For more details regarding configuring the GPIOs on this header, refer to the Open-Q 865XR SOM
Software Release Notes to determine feature support in the latest software release.
Special Notes:
GPIO_15_RADAR_INT (pin 6) is shared with the Boot LED (see section 3.7.7) on the
•
development kit. In order to use GPIO_15 on the sensor header, R2409 should be removed and
software changes are needed to remove the boot LED functionality. See R-3 schematics for
details.
3.7.19

Audio Inputs Expansion Header J1800 (27)

The Open-Q 865XR SOM Development Kit audio subsystem is built around the Qualcomm Audio Codec
WCD9385 (28). The Audio Inputs Expansion Header J1800 exposes some of the audio input capabilities
of WCD9385 for the user. See item 27 in Figure 1 for the carrier board location of this header. The pinout
for this header is shown in the table below.

Table 15. Audio Inputs Expansion Header Pinout J1800

Pin
Signal
No
1 CDC_IN1_P
3 CDC_IN6_P
5 CDC_MIC_BIAS1
7 CDC_IN7_P
Open-Q 865XR SOM Development Kit User Guide
(SSC0_I2C_SDA
)
GPIO_161 /
SSC1
(SSC0_I2C_SCL)
GPIO_167 /
SSC7
(SSC2_SPI0_CS
_0)
GPIO_166 /
SSC6
(SSC2_SPI0_CL
K)
GPIO122
Description
Codec Input 1 Positive
Codec Input 6 Positive
Microphone Bias 1
Codec Input 7 Positive
3: Open-Q 865XR SOM Development Kit
18 GPIO_129_PRESS_INT
GPIO_165_SNS_SPI2_M
20
OSI
GPIO_164_SNS_SPI2_M
22
ISO
24 GPIO_64_SAR_INT_N
Pin
Signal
No
2 CDC_IN1_N
4 CDC_IN6_N
6 CDC_MIC_BIAS3
8 CDC_IN7_N
GPIO129
GPIO_165 /
SSC5
(SSC2_SPI0_MO
SI)
GPIO_164 /
SSC4
(SSC2_SPI0_MIS
O)
GPIO64
Description
Codec Input 1 Negative
Codec Input 6 Negative
Microphone Bias 3
Codec Input 7 Negative
34
