Table 1. List of Development Kit Features itemized in the figure above

Position Feature Description
1 DC Power Supply Jack
2 Power Source Selector
3 Battery Input Header
4 Battery Configuration DIP Switch
5 USB 3.1 Type A Connector
6 M.2 PCIe USB Enable DIP Switch
7 Buttons: General Purpose / Power / Volume Up / Volume Down
8 Audio Headset Jack
9 Debug UART Header
10 Audio I/O Header
11 USB 3.1 Type-C connector for ADB
12 USB Serial Debug Console
13 WLAN/BT Channel 0 External Antenna Connector
14 WLAN Channel 1 External Antenna Connector
15 Camera 1 Connector
16 Camera 2 Connector
17 Camera 3 Connector
18 Camera 1 Option Header
19 Camera 2 Option Header
20 Camera 3 Option Header
21 Sensors Expansion Header
22 Micro SD card socket (on bottom side of Carrier Board)
23 Digital IO Expansion Header
Open-Q 865XR SOM Development Kit User Guide
3: Open-Q 865XR SOM Development Kit
Reference Designator
J400
S300
J300
S301
J2300
S2301
S2401 / S2403 / S2400
/ S2402
J1700
J1501
J1900
J2200
J1500
J2601
J2600
J1000
J1100
J1200
J1001
J1101
J1201
J2000
J1400
J2100
