DUAL MEDIUM INTENSITY LED/STROBE
2.4.3 Connect the "NEUTRAL" side of the 120V AC line to TB1-10.
2.4.4 Connect the AC ground to the ground stud to the lower right of the terminal
2.4.5 Controller panel should be connected to the tower and/or building grounding
2.5

TOWER LIGHTING KIT

When installing this system, the customer will need to use strobe cable wiring
method to wire the STLDBEACON. Refer to tower kit drawing 602, for cable
installations.
THIS SYSTEM OPERATES AT HIGH VOLTAGE LEVELS THAT COULD
BE LETHAL TO SERVICE PERSONNEL. ALL INSTALLATION AND
MAINTENANCE WORK SHOULD BE DONE BY QUALIFIED SERVICE
PERSONNEL ONLY. WHEN PERSONNEL IS INSTALLING SYSTEM OR
PERFORMING MAINTENANCE ON THIS SYSTEM, MAKE SURE THE
POWER IS TURNED OFF AT THE SERVICE BREAKER PANEL!!
READ AND UNDERSTAND THE THEORY OF OPERATION AND ITS
SAFETY MESSAGES BEFORE ATTEMPTING INSTALLATION/MAIN-
TENANCE OF THIS SYSTEM. DO NOT ATTEMPT TO DEFEAT THE
INTERNAL SAFETY SWITCHES IN THE CONTROLLER AND
STLDBEACON!!
2.5.1 LED Red Beacon Mounting and Wiring (Refer to Drawings HDO-264, and
M.2006 MANUALS.E-1DBSL
REV. 08/10/04, 12/09/05, 2/08/06, 04/11/06 (load resistor)
REV. 06/21/06 (part numbers), 7/13/06 (Appendix & 6.0 Major Comp. List)
REV 10/20/06 (Appendix & parts lists)
REV. 04/10/07 (text)
MODEL E-1DBSL
block TB1.
system with the exception of installations on AM RF applications where
controller grounding to earth ground is prohibited. Ground the controller
only to the tower itself using a suitable RF ground.
WARNING DANGER!!!
INS-264)
