DUAL MEDIUM INTENSITY LED/STROBE
2.3 PHOTOCELL WIRING (Refer to Drawings HDO-264 and H40-264)
If the control cabinet is mounted inside an equipment building, the photocell should
be mounted vertically on ½" conduit outside the building above the eaves facing
north. Wiring from the photocell housing socket to the control cabinet should consist
of one (1) each; red, black, and white wires. The white wire is connected to the
socket terminal marked "N," the black wire is connected to the socket terminal
marked "L," and the red wire is connected to the socket terminal marked "LO." The
photocell should be positioned so that it does not "see" ambient light, which would
prevent it from switching to the nightmode. If the control cabinet is mounted outside
an equipment building, the photocell should be mounted vertically on ½" conduit so
the photocell is above the control cabinet. Care must be taken to assure that the
photocell does not "see" any ambient light that would prevent it from switching into
the nightmode. The photocell housing socket wiring is the same as above.
2.3.1 Connect the BLACK wire from the photocell to TB1-6.
2.3.2 Connect the RED wire from the photocell to TB1-7.
2.3.3 Connect the WHITE wire from the photocell to TB1-8.
2.3.4 Install the photocell into the receptacle and twist to the right while depressing
2.4 POWER WIRING (Refer to Drawing H40-264)
Power wiring to the control cabinet should be in accordance with local methods and
the National Electric Code (NEC).
2.4.1 A 15 amp circuit breaker is recommended at service panel.
2.4.2 Connect the "HOT" side of the 120V AC line to TB1-9.
M.2006 MANUALS.E-1DBSL
REV. 08/10/04, 12/09/05, 2/08/06, 04/11/06 (load resistor)
REV. 06/21/06 (part numbers), 7/13/06 (Appendix & 6.0 Major Comp. List)
REV 10/20/06 (Appendix & parts lists)
REV. 04/10/07 (text)
MODEL E-1DBSL
to lock into place.
