2.5.1.1 Bolt the STLDBEACON to the mounting plate using four 5/8" x 1
1/4" galvanized bolts that are supplied. Installer should make sure
to check for full thread engagement on Anco locknut. Allow 16"
clearance in back of the hinge (25" from the center of the base) to
tilt lens back without hitting an obstruction.
2.5.1.2 Level the STLDBEACON using the spirit level at the base of the
lens. Shims may be used under beacon base or triple nutting each
bolt with palnuts on all four (4) nuts.
2.5.1.3 Slip the electrical cable for the STLDBEACON through the
watertight connector (cable gland bushing), and tighten the gland
nut to make a watertight seal. Attach the wires to the terminal
strip as follows:
Connect Cable
Wire Color
10 Gauge Red
14 Gauge White/Green
16 Gauge Brown
16 Gauge Blue
10 Gauge Black
14 Gauge White
14 Gauge Green
10 Gauge Red/Black
16 Gauge Bare Wire
To Lamp platform
Match Wire Color
16 Gauge Red
16 Gauge White/Green
16 Gauge Brown
16 Gauge Blue
16 Gauge Black
16 Gauge White
16 Gauge Green
16 Gauge Red/Black
Beacon Base
4
Terminal
Block Number
1
2
3
4
5
6
7
8
