DUAL MEDIUM INTENSITY LED/STROBE
2.6

ALARM WIRING

Individual alarm contacts (Form C) are provided for strobe failures, power failure,
and photocell on. It is left up to the customer or installer on how they choose to
utilize these contacts with their monitoring equipment.
equipment is available. Please inquire within the sales staff at the factory for models
available and pricing. Alarm configurations are shown on drawings H40-264, and
M01-264.
M.2006 MANUALS.E-1DBSL
REV. 08/10/04, 12/09/05, 2/08/06, 04/11/06 (load resistor)
REV. 06/21/06 (part numbers), 7/13/06 (Appendix & 6.0 Major Comp. List)
REV 10/20/06 (Appendix & parts lists)
REV. 04/10/07 (text)
MODEL E-1DBSL
2.5.2.5 Connect the 16 gauge Blue wire from STLDBEACON wiring to
TB1-5.
2.5.2.6 Connect the 10 gauge Red wire from STLDBEACON wiring to
Fuse Block marked "B."
2.5.2.7 Connect the 14 gauge White/Green wire from STLDBEACON
wiring to TB1-11.
2.5.2.8 Connect the 14 gauge Green wire from STLDBEACON ground
back panel.
2.5.2.9 Connect the Neutral wire from sidelight wiring to TB1-12.
2.5.2.10 Connect the Red wire from the sidelight wiring to Fuse Block
marked "S."
2.5.2.11 Connect the ground wire (if cable is used) from sidelight wiring to
ground screw left of TB1.
External monitoring
7
