DUAL MEDIUM INTENSITY LED/STROBE
5.0

MAINTENANCE GUIDE

**WARNING - HIGH - VOLTAGE**
THIS SYSTEM OPERATES AT HIGH VOLTAGE LEVELS THAT COULD BE
LETHAL
MAINTENANCE WORK MUST BE DONE BY QUALIFIED SERVICE
PERSONNEL. READ AND UNDERSTAND THE THEORY OF OPERATION AND
ITS SAFETY MESSAGES BEFORE ATTEMPTING INSTALLATION OF THIS
SYSTEM. DO NOT ATTEMPT TO DEFEAT THE INTERNAL SAFETY DEVICES.
Tools Required: #2 Phillips Screwdriver
5.1

FLASHTUBE REPLACEMENT

The only required maintenance needed to be performed is the replacement of the
flashtube every four (4) years. By following these instructions, maximum safety and
performance can be achieved.
5.1.1 Loosen the single quick open bolt located on upper hinge assembly.
5.1.2 Open the lens and tilt it back.
5.1.3 Loosen the three (3) socket screws with a #2 Phillips screwdriver to remove
5.1.4 Install the new flashtube, making sure that the pins are aligned with the
5.1.5 Tighten the socket screws snug, then 1/4 turn more.
5.1.6 Close the lens. Make sure nothing hampers the safety interlock action.
5.1.7 Re-tighten the single quick open bolt on the STLDBEACON hinge.
M.2006 MANUALS.E-1DBSL
REV. 08/10/04, 12/09/05, 2/08/06, 04/11/06 (load resistor)
REV. 06/21/06 (part numbers), 7/13/06 (Appendix & 6.0 Major Comp. List)
REV 10/20/06 (Appendix & parts lists)
REV. 04/10/07 (text)
MODEL E-1DBSL
TO SERVICE PERSONNEL.
3/16 Flat Blade Screwdriver
ALWAYS WAIT AT LEAST 30 SECONDS AFTER OPENING THE
STLDBEACON BEFORE STARTING ANY WORK.
lamp.
socket. Make sure tube is flush on the socket.
ALL INSTALLATION AND
