TWR Lighting E-1DBSL Manual page 49

4
23
6
4
12
5
B
38
13
3
32
47
6
55
58
75
18
6
36
68
22
21
16
42
28
72
66
55
65
8
20
73
A
56
4
3
2
1
39
41
24
41
64
70
50
46
3
25
48
49
19
42
67 57
69
34
35
9
37
17
74
41
58
75
20
71
65
63
62
38
26
51
DRAWN
Gavin Sebek
3/3/2004
CHECKED
QA
MFG
APPROVED
2
ITEM QT PART NUMBER
1 1 100319
2 3 BU27200
3 6 1032X12PHH
4 3 115510SS0
5 6 1032FW
6 10 18PRSS-2
7 2 7X7SS
8 1 2-10000
9 3 14FWDB
10 2 * 18AWG BLU
11 2 * 18AWG BRN
12 1 121340712
13 24 8NFW
14 2 14X34CLVP
15 1 14X358CLVP
16 1 STCONLAB2
17 3 12SSCP
18 1 1261
19 1 STJ02003
20 6 (stdbframkit) 100337
21 1 (stdbframkit) 100343
22 1 (stdbframkit) 100345
23 6 (stdbframkit) 100368
27
24 1 (stdbframkit) 100396
25 1 (stdbframkit) 100344
26 1 (stdbframkit) 100360M
7 27 1 (stdbframkit) 100342
28 1 121102013
29 1 070-4500
30 1 * 16AWGBLK
36
31 1 * 16AWG RED/WHT
32 1 INDCTRC3001
33 1 * 16AWG RED/BLK
34 1 STC05005
43
35 1 1032X38PHH
36 3 832X14PHH
37 2 632X38PHH
38 24 1032X38PHW
39 3 832NUT
15
40 2 * 18RAD18277
41 5 832X12PHH
42 2 STBEAGSKT
29
43 2 STBEAGSK2
44 14 * TYZ23M
45 1 * 14RB10R
46 1 EL190S
17
47 1 100394-02
48 1 STDBCLENS
49 1 STFLSHTB8
50 1 A315
9
51 4 58X112
52 1 * HEATSHRINK2
53 4 CSL062X100
14
54 .25 * HEATSHRINK
55 1 57-10-401-10
56 1 CC-MPT-1-G
57 1 TYANCHOR
58 2 TERMBLK141-8
13
59 23 * 18RA6FL
60 7 * 14RB-6FL
61 3 * KV10-8F-D
62 1
STLDBCTUBE
63 1 LEDLITEENG
64 1 STBEAGSK3
65 4 1420X81316AT
66
66 12 1420SSNUTN
67 5 632X14PHH
68 3 832X58PHH
69 2 (stldsubkit) 100599M
70 2
(stldsubkit) 100606i
71 1 (stldsubkit) 100605i
72 1 (stldsubkit) 100602M_RA
73 1 (stldsubkit) 100601M_RA
74 1 NONOEMLBL
75 2 TERMARKSTRIP-8B
* = ITEMS NOT SHOWN
43
66
13
TWR Lighting, Inc.
Enlightened Technology
TITLE
L865/864LED DUAL BEACON ASSEMBLY
(STLDBEACON)
SIZE
DWG NO
100604
B
SCALE
2
1
Parts List
DESCRIPTION
DUAL BEACON FLASHTUBE SOCKET
FLASHTUBE SOCKET INSERT
10-32 X 1/2 PHILLIPS BINDER SCREW
5/16 X 1/4 ROUND SS SPACER
#10 SS FLAT WASHER
1/8 X .40 SS POP RIVET
1/16 HOL 7 X 7 SS WIRE
CIRCULAR SPIRIT LEVEL
1/4 FLAT WASHER CH16L
#18AWG TEFLON BLUE WIRE
#18AWG TEFLON BROWN WIRE
DB QUICK OPEN CAPTIVE SCREW
#8 NYLON FLAT WASHER
1/4 X 3/4 SHORT SS CLEVIS PIN
1/4 X 3-5/8 LONG SS CLEVIS PIN
Product Label
1/2" SS COTTER PIN
SS RETAINER FOR QUICK OPEN
CHERRY SWITCH
DUAL BEACON LENS RETAINER RING
DUAL BEACON LOWER HINGE ASSEMBLY
DUAL BEACON HATCH PLATE
DUAL BEACON CAP BRACKET
INDUCTOR BRACKET
CAP DUAL BEACON
DUAL BEACON BASE ASSEMBLY (DRILLED)
B
DUAL BEACON UPPER HINGE ASSEMBLY
DB QUICK OPEN SCREW FLAT RECEPTACLE
DB HATCH SPRING SS DWG100558
#16AWG TEFLON BLACK WIRE
#16AWG TEFLON RED/WHITE WIRE
INDUCTOR .47MH TRANSFORMER
#16AWG TEFLON RED/BLACK WIRE
TRIGGER TRANSFORMER
10-32 X 3/8 PILLIPS PAN HEAD SCREW
8-32 X 1/4 PH SS SLOT SCREW
6-32 X 3/8 PHILLIPS PAN HEAD SCREW
10-32 X 3/8 SS PHILIP HD CAPTIVE SCREW
8-32 NUT
T&B CONNECTOR
8-32 X 1/2 PHILLIPS PAN HEAD
GASKET NEOPRENE 13 1/4 X 15
GASKET NEOPRENE 3/16 X 15 1/4
HI TEMP TY WRAPS
T&B CONNECTOR
1" 90 DEGREE SHORT ELBOW GALV
INDUCTOR BOTOM PAD GASKET
CLEAR DB LENS
FLASH TUBE 2-TURN HELIX
1" CONDUIT LOCKNUT GALVANIZED
A325 5/8 X 1-1/2 BOLT W/ANCO L/NUT
1/2" GLUE BASE HEAT SHRINK
1/16 COPPER SLEEVE
1/4" RED HEAT SHRINK
SOUTHCO SPRING LATCH W/BLACK KNOB
1" CORD CONNECTOR .700 TO .984
TY WRAP ANCHOR 23N3669
8 PART TERMINAL BLOCK
STAKON
14-16 AWG #6 LOCKING FORK
10-12 AWG #8 LOCKING FORK
CLEAR ACRYLIC TUBE 14"
120 VAC L-864 LED LIGHT ENGINE
GASKET NEOPRENE 1/16 X 15-1/4
14-20 X 8-13/16 S/S
1/4-20 S/S NUT W/NYLON
6-32 X 1/4 PHILLIPS PAN HEAD SCREW
8-32 X 5/8 PHILLIPS PAN HEAD SCREW
HATCH PLATE VENT COVER
RETAINING WASHER
TERMINAL MOUNTING PLATE
TOP LED ENGINE PLATE
BOTTOM LED ENGINE PLATE
NON-OEM PARTS WARNING LABEL
MS8-141 CINCH TERMINAL MARKER
A
REV
SHEET 1 OF 1
1
