DUAL MEDIUM INTENSITY LED/STROBE
LEDs on PCB #1 are numbered from top to bottom, 1-9. LEDs on PCB #2 are numbered
from top to bottom, D14 - D16. The following chart will indicate normal LED operation.
INDICATOR
LED 2
LED5
LED4
LED6
LED7
LED8
LED9
D14
4.3

TROUBLESHOOTING ASSISTANCE

4.3.1 Strobe Flash Verify LED - Out

M.2006 MANUALS.E-1DBSL
REV. 08/10/04, 12/09/05, 2/08/06, 04/11/06 (load resistor)
REV. 06/21/06 (part numbers), 7/13/06 (Appendix & 6.0 Major Comp. List)
REV 10/20/06 (Appendix & parts lists)
REV. 04/10/07 (text)
MODEL E-1DBSL
OPERATION
Strobe Fail Test
Flash Verify

Control Power ON

Trigger Voltage

Failsafe Mode

Primary Timing

Timing Verify

High Voltage #1

4.3.1.1 Observe high voltage LED (D14) on the high voltage rectifier PCB
#2, to determine if it is available. If the LED is dim or out
completely, then check the high voltage capacitor bank (C103 -
C109 daymode, C102 nightmode) for a short. If no capacitor is
found to be shorted, check the resonant cap (C101) for a short. If
the resonant cap is okay, replace PCB #2. If the LED is at full
illumination, go to the next step.
4.3.1.2 Check the status of trigger LED6. If LED is off, check fuse F2. If
blown, replace with exact type of fuse. If the fuse blows again,
replace PCB #1. Check transformer T1. Replace as necessary. If
LED is okay, go to the next step.
4.3.1.3 If steps 4.3.1.1 and 4.3.1.2 check out okay, re-lamp the
STLDBEACON.
NORMAL STATUS
Normal OFF/Flashes in Test Mode
Steady ON During Failsafe Mode
Steady ON when Voltage Above 50V DC
Blinks
Steady ON
Steady ON
Operation
Flashing
Flashing
17
