DUAL MEDIUM INTENSITY LED/STROBE
2.5.2 Lighting Kit Wiring
M.2006 MANUALS.E-1DBSL
REV. 08/10/04, 12/09/05, 2/08/06, 04/11/06 (load resistor)
REV. 06/21/06 (part numbers), 7/13/06 (Appendix & 6.0 Major Comp. List)
REV 10/20/06 (Appendix & parts lists)
REV. 04/10/07 (text)
MODEL E-1DBSL
Install wiring between the controller and the beacon utilizing strobe cable.
(TWR LIGHTING CANNOT WARRANTY SYSTEMS THAT
EMPLOY SPLICING CABLE.) Refer to drawings HDO-264 and 602 for
installation of light kits. Following these minimum guidelines, as well as any
local or end user additional requirements, installing light kits will require
lifting of the cable by the supplied cable grip or conduit to affix to the tower.
Always work safely and adhere to all OSHA Safety Guidelines when lifting
wiring or working on the structure or tower itself. It is the installer's
responsibility to install the lighting kit in a safe manner. Installers can
request from OSHA their requirements 29CFT 1926.21, and 29CFR
1926.105, to ensure compliance to regulations.
NOTE: On occasion, a set of custom lighting kit drawings may be
specifically requested by a customer and installed in this manual. In cases
such as this, the drawings will precede the manual if a conflict occurs.
All the necessary information for wiring the STLDBEACON and sidelights
is contained on the tower kit drawing 602. The connections for the
STLDBEACON and sidelights in the controller are as follows:
2.5.2.1 Connect the 10 gauge Red/Black wire from STLDBEACON
wiring to TB1-1.
2.5.2.2 Connect the 10 gauge Black wire from STLDBEACON wiring to
TB1-2.
2.5.2.3 Connect the 14 gauge White wire from STLDBEACON wiring
to TB1-3.
2.5.2.4 Connect the 16 gauge Brown wire from STLDBEACON wiring to
TB1-4.
