4
7
B
9
6
14
12
A
5
3
4
3
11
DRAWN
gsebek
1
CHECKED
GDS
QA
23
MFG
APPROVED
3
2
ITEM
QTY
PART NUMBER
1
1
105V
1
106V
2
3
2
HC255SS
4
1
OLG2
5
16
18PRSS
6
.5
7X7SS
7
2
A1A
8
1
A314
9
2
12V245
10
2
832X14PH
11
1
N400C
12
1
PS90-260/24
13
6
STE01-047
14
1
100588
15
1
100591
10
16
6
STD05006
17
1
A10290
18
.3
* 20RED
19
3
632X14PHH
20
1
* 14GREEN
21
3
* WIRENUTBLU
22
1
* 14RB6R
23
1
100680
* = ITEMS NOT SHOWN
2
15
16
13
7.342"
17
5
2.368"
19
4
8
FIXTURE
120/240VAC
TWR Lighting, Inc.
6/24/2005
9/27/2006
TITLE
OL1VLED2 120VAC FAA-OL16LED
(L810 OBSTRUCTION LIGHT)
SIZE
B
SCALE
2
1
Parts List
DESCRIPTION
VALOX SINGLE SIDE HUB BODY
VALOX LENS HOLDER RING
SIDELIGHT LATCH
OL1 6 LED GASKET
1/8 X .45 SS POP RIVET
1/16 HOL 7X7 S.S. WIRE
STAKON CRIMP
3/4" CONDUIT LOCKNUT
OL LENS CLIP
8-32 X 1/4 PH SS SLOT SCREW
SIDELIGHT LENS CLEAR ACYRLIC
POWER SUPPLY
LED VERTICAL PCB
OL 6LED BASE PLATE
OL 6LED STAR DISK
LED EMITTER
5/32" ID RUBBER GROMMET
#20AWG RED BELDON WIRE
6-32 X 1/4 PH PH SCREW
#14AWG GREEN BELDON WIRE
WIRE NUT FOR #6 WIRE
RING TERMINAL (GROUND WIRE)
OL1/2 LED SERIAL # LABEL
4.813"
* GROUND WIRE MUST BE CONNECTED
TO PROPERLY PROTECT POWER SUPPLY.
FAILURE TO GROUND WILL VOID ALL
WARRANTIES.
Enlightened Technology
DWG NO
100656
1
1
SHEET
OF
1
B
A
REV
A
