POWER WIRING

(Refer to Drawing H40-329)
Power wiring to the control cabinet should be in accordance with local methods and
the National Electric Code (NEC).
2.4.1
2.4.2
2.4.3
2.4.4
2.4.5 Controller panel should be connected to the tower and/or building grounding
2.5

TOWER LIGHTING KIT

When installing this system, the customer will need to use strobe cable wiring
method to wire the strobe beacon. Refer to drawing 600-04 for cable installations.
M.E-2009.E-1DB2
3/25/07 – rev. 5/28/09
E-1DB2 CONTROLLER
Connect the BLACK wire from the photocell to TB1-8.
Connect the RED wire from the photocell to TB1-9.
Connect the WHITE wire from the photocell to TB1-10.
Install the photocell into the receptacle and twist to the right while depressing
to lock into place.
A 15 amp circuit breaker is recommended at service panel.
Connect the "HOT" side of the 120V AC line to TB1-11.
Connect the "NEUTRAL" side of the 120V AC line to TB1-12.
Connect the AC ground to the ground stud to the lower right of the terminal
block TB1.
system with the exception of installations on AM RF Applications where
controller grounding to earth ground is prohibited. Ground the controller only
to the tower itself using a suitable RF ground.
