10810 W. LITTLE YORK RD., #130 - HOUSTON, TX 77041-4051
VOICE (713) 973-6905 - FAX (713) 973-9352
PLEASE TAKE THE TIME TO FILL OUT THE FORM COMPLETELY. FILE IN
A SAFE PLACE. IN THE EVENT YOU EXPERIENCE PROBLEMS WITH OR
HAVE
QUESTIONS
FOLLOWING INFORMATION IS NECESSARY TO OBTAIN PROPER
SERVICE AND PARTS.
MODEL #
SERIAL #
PURCHASE DATE
PURCHASED FROM
M.2016.D.D-1LVS
10-14-08 – REV 6-23-16
web: www.twrlighting.com
IMPORTANT!!!
CONCERNING
YOUR
CONTROLLER,
D-1LVS
THE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D-1LVS and is the answer not in the manual?

Questions and answers

Related Manuals for TWR Lighting D-1LVS

Summary of Contents for TWR Lighting D-1LVS

  • Page 1 A SAFE PLACE. IN THE EVENT YOU EXPERIENCE PROBLEMS WITH OR HAVE QUESTIONS CONCERNING YOUR CONTROLLER, FOLLOWING INFORMATION IS NECESSARY TO OBTAIN PROPER SERVICE AND PARTS. MODEL # D-1LVS SERIAL # PURCHASE DATE PURCHASED FROM M.2016.D.D-1LVS 10-14-08 – REV 6-23-16...

  • Page 2: Table Of Contents

    D-1LVS CONTROLLER TABLE OF CONTENTS INTRODUCTION ......................... 1 APPLICATION ......................1 SPECIFICATIONS OF EQUIPMENT ..............1 INSTALLATION ........................2 POWER SUPPLY CONTROL CABINET MOUNTING .......... 2 PHOTOCELL HOUSING ..................2 PHOTOCELL WIRING ................... 2 POWER WIRING ....................3 TOWER LIGHTING KIT ..................3 2.5.1...
  • Page 3 D-1LVS CONTROLLER TROUBLESHOOTING ..................... 11 TOOL REQUIREMENTS ..................11 DIAGNOSTIC EVALUATION ................11 TROUBLESHOOTING ASSISTANCE ..............12 4.3.1 Flash Verify LED - Out ................12 4.3.2 Control Power On LED - Out ..............12 4.3.3 Primary Timing LED Out................. 13 4.3.4...
  • Page 4 APPENDIX CHASSIS COMPONENT LAYOUT ............H40-283 (REV F) SCHEMATIC LAYOUT ................. M01-283 (REV B) HOUSING DETAILS D-1LVS ............... HD0-283 (REV B) INSTALLATION GUIDELINE ................INS-283 PHOTOCELL HOUSING DETAIL ............100239 (REV H) TOWER LIGHTING KIT - CABLE ............500-12 (REV B) CONTROL PCB #1 ................

  • Page 5: Introduction

    APPLICATION The D-1LVS L-865 Controller is for use on lighting structures or towers that are approved to be lighted with Medium Intensity Strobes in accordance with the FAA’s Advisory Circular 70/7460-1K.

  • Page 6: Installation

    D-1LVS CONTROLLER INSTALLATION POWER SUPPLY CONTROL CABINET MOUNTING The power supply control cabinet can be located at the base of the structure or in an equipment building. Mounting Dimensions can be found in Section 1.2, on page 1. Pay particular attention when choosing your controller mounting location to ensure proper door opening and room for service personnel.

  • Page 7: Power Wiring

    D-1LVS CONTROLLER 2.3.4 Install the photocell into the receptacle and twist to the right while depressing to lock into place. POWER WIRING (Refer to Drawing H40-283) Power wiring to the control cabinet should be in accordance with local methods and the National Electric Code (NEC).

  • Page 8: Lighting Kit Wiring

    D-1LVS CONTROLLER 2.5.2 Lighting Kit Wiring Install wiring between the controller and the beacon utilizing strobe cable (TWR LIGHTING CANNOT WARRANTY SYSTEMS THAT method. EMPLOY SPLICING CABLE.) Refer to drawings HDO-283 and 500-12 for install of lighting kits. Follow these minimum guidelines as well as any local or end user addition requirements.

  • Page 9: Power Failure (Pf)

    D-1LVS CONTROLLER 2.6.3 Power Failure (PF) While the controller is in normal operation, shut off power to the controller at the breaker panel. Alarm should be prompt. Reset breaker to resume normal operation. 2.6.4 Photocell (PC) Controller should be in the daymode of operation when performing this test.

  • Page 10: Theory Of Operation

    D-1LVS CONTROLLER THEORY OF OPERATION THE POWER SUPPLY The AC line is sent to transformer T1 through fuse F1 and relay K1. In order for K1 to energize and complete the circuit to T1, the safety interlock switch CSS, BSS, must be closed.

  • Page 11: Timing Circuit

    D-1LVS CONTROLLER The flashtube contains a gas called Xenon. When the high voltage energy in the storage capacitors is connected to the flashtube, nothing will happen since Xenon in its natural state is not a conductor of electricity. However, when a very short duration...

  • Page 12: Photocell (Pc)

    D-1LVS CONTROLLER The power failure alarm relay is energized during normal operation. Should the power be removed for any reason, then relay K6 would drop, creating an alarm for the customer alarm transmitting device. 3.5.2 Photocell (PC) The photocell alarm relay is energized whenever the photocell or SW3 is on.

  • Page 13: High Voltage

    D-1LVS CONTROLLER 3.7.2 High Voltage The Cathode side of the high voltage HV is routed through current limiting resistor. When the unit is in daymode, D14 will be at full brightness when the capacitors are at full charge, but dims with the discharging of the storage capacitors.

  • Page 14: Flash Verified

    D-1LVS CONTROLLER 3.7.7 Flash Verified Current from the Cathode side of the flashtube (FTC) is sent through the current sensing transformer T1 on PCB #1. T1 will send a pulse to the gate of the SCR’s Q2 and turns it on. Capacitor C11 via Q2 will send voltage to LED5 (D8).

  • Page 15: Troubleshooting

    D-1LVS CONTROLLER TROUBLESHOOTING Much of the troubleshooting of this system will consist of correcting a “beacon out” situation. There may also be a failure mode where the flashtube is still flashing, but at the wrong rate or the wrong intensity.

  • Page 16: Troubleshooting Assistance

    D-1LVS CONTROLLER LEDs on PCB #1 are numbered from top to bottom 1-9. LEDs on PCB #2 are numbered from top to bottom D14 - D16. The following chart will indicate normal LED operation. INDICATOR OPERATION NORMAL STATUS LED 1...

  • Page 17: Primary Timing Led Out

    D-1LVS CONTROLLER 4.3.3 Primary Timing LED Out Observe the status of the timing LED. If the LED is dim or out completely, check LED9, if dim or out, replace PCB #1. If one or both are lit, you should have timing.

  • Page 18: Maintenance Guide

    D-1LVS CONTROLLER ***W A R N I N G - H I G H - V O L T A G E*** THIS SYSTEM OPERATES AT HIGH VOLTAGE LEVELS THAT COULD BE LETHAL TO SERVICE PERSONNEL. ALL INSTALLATION AND MAINTENANCE WORK SHOULD BE DONE BY QUALIFIED SERVICE PERSONNEL.

  • Page 19: Major Components Parts List

    100273 MOV1, MOV2 METAL OXIDE VARISTOR MOV524V15 MOV3 METAL OXIDE VARISTOR V1000LA80A 15 POSITION PLUG STT60021 PCB #1 D-1LVS CONTROL PCB STH01226B PCB #2 HIGH VOLTAGE RECTIFIER PCB STH02226A PCB #3 RELAY PCB STH03226 6390-FAA2 PHOTOCELL 120 – 240V AC PHOTOCELL...
  • Page 20 D-1LVS CONTROLLER MAJOR COMPONENTS PARTS LIST (continued) SCHEMATIC TAG # DESCRIPTION TWR PART # ISOLATION TRANSFORMER STC05004 FERRORESONANT STC30018 TRANSFORMER TRIGGER TRANSFORMER STC05005 10 PART TERM BLK TERMBLK - 10 12 PART TERM BLK TERMBLK 141 - 12 THERMAL LIMITING SWITCH...

  • Page 21: Recommended Spare Parts List

    D-1LVS CONTROLLER RECOMMENDED SPARE PARTS LIST PART NUMBER DESCRIPTION STH01226B D-1LVS PRINTED CIRCUIT BOARD STJ10006 DPDT CONTACTOR RELAY STFLSHTB5 STROBE FLASHTUBE 6390-FAA2 (This replaces the P2455L 120 – 240V AC PHOTOCELL Photocell) KTK10 10 amp FUSE FLQ18 1/8 amp FUSE FUSE .5...

  • Page 22: Warranty & Return Policy

    D-1LVS CONTROLLER Warranty & Return Policy ® ® TWR Lighting , Inc. (“TWR ”) warrants its products (other than “LED Product”) against defects in design, material (excluding incandescent bulbs) and workmanship for a period ending on the earlier of two (2) years from the date of shipment or one (1) year from the date of installation.
  • Page 23 The warranty is null and void if the product(s) are damaged in the return shipment. ® All RMAs must be received by TWR LIGHTING , INC., 10810 W. LITTLE YORK RD. #130, HOUSTON, TX 77041-4051, within 30 days of issuance.
  • Page 24 D-1LVS CONTROLLER Warranty & Return Policy (continued) RMA Replacements – Replacement part(s) will be shipped and billed to the customer for product(s) considered as Warranty, pending return of defective product(s). When available, a certified reconditioned part is shipped as warranty replacement with a Return Merchandise Authorization (RMA) number attached.
  • Page 25 D-1LVS CONTROLLER Warranty & Return Policy (continued) Freight – All warranty replacement part(s) will be shipped via ground delivery and paid for by ® . Delivery other than ground is the responsibility of the customer. REMEDIES UNDER THIS WARRANTY ARE LIMITED TO PROVISIONS OF REPLACEMENT PARTS AND REPAIRS AS SPECIFICALLY PROVIDED.

  • Page 26: Return Merchandise Authorization (Rma) Form

    D-1LVS CONTROLLER RETURN MERCHANDISE AUTHORIZATION (RMA) FORM RMA#: DATE: CUSTOMER: CONTACT: PHONE NO.: ITEM DESCRIPTION (PART NO.): MODEL NO.: SERIAL NO.: ORIGINAL TWR INVOICE NO.: DATED: DESCRIPTION OF PROBLEM: SIGNED: DATE NEEDED: RETURN ADDRESS: PLEASE RETURN PRODUCT TO: 10810 W. LITTLE YORK RD., #130 HOUSTON, TX 77041-4051 M.2016.D.D-1LVS...
  • Page 27 D-1LVS CONTROLLER RETURN MERCHANDISE AUTHORIZATION (RMA) FORM RMA#: DATE: CUSTOMER: CONTACT: PHONE NO.: ITEM DESCRIPTION (PART NO.): MODEL NO.: SERIAL NO.: ORIGINAL TWR INVOICE NO.: DATED: DESCRIPTION OF PROBLEM: SIGNED: DATE NEEDED: RETURN ADDRESS: PLEASE RETURN PRODUCT TO: 10810 W. LITTLE YORK RD., #130 HOUSTON, TX 77041-4051 M.2016.D.D-1LVS...
