DUAL MEDIUM INTENSITY LED/STROBE
PART NUMBER
PRD5AYO
STH02226A
DTK-120HW
STH03264A
P2455L
KTK1
KTK2
FS15530T
TS14130
STA08018
STA08015
STA08010
STJ01004
STC05004
STC30018
TERMBLK-12
TERMBLK 141 – 12
STJ10008
STLDBEACON
STDBCLENS
M.2006 MANUALS.E-1DBSL
REV. 08/10/04, 12/09/05, 2/08/06, 04/11/06 (load resistor)
REV. 06/21/06 (part numbers), 7/13/06 (Appendix & 6.0 Major Comp. List)
REV 10/20/06 (Appendix & parts lists)
REV. 04/10/07 (text)
MODEL E-1DBSL
DESCRIPTION
DAY/NIGHT RELAY
HIGH VOLTAGE RECTIFIER PCB
SURGE ARRESTOR 120V AC
RELAY PCB w/ALARM LOCKOUT
ELIMINATION MODIFICATION
120V AC PHOTOCELL
1 amp FUSE
2 amp FUSE
FLASHER SOLID STATE
TIMER
150 ohm 100W
35k 20W
2.4 meg 2W
SPDT 15 amp SWITCH
ISOLATION TRANSFORMER
FERRORESONANT
TRANSFORMER
12 PART TERM BLK
12 PART TERM BLK
THERMAL LIMITING SWITCH
STROBE LED BEACON
STROBE BEACON LENS
SCHEMATIC TAG #
K3
PCB #2
MOV1
PCB #3
PHOTOCELL
F4
F5
M3
M4
R31
R32
R33
SW3
T2
T1
TB1
TB2
TLS
23
