DUAL MEDIUM INTENSITY LED/STROBE
6.0

MAJOR COMPONENTS LIST

PART NUMBER
STJ02003
STB99006
STB99008CSI
STB99008
STJ02001
FNQ10
FLQ 1/8
FUSE .5
STFLSHTB8
KRPA11AG120
KRPA5AG120
SPEC 218
STJ10016
INDCTR3001
100273
MOV524V15
V1000LA80A
STT60021
STH01226B
M.2006 MANUALS.E-1DBSL
REV. 08/10/04, 12/09/05, 2/08/06, 04/11/06 (load resistor)
REV. 06/21/06 (part numbers), 7/13/06 (Appendix & 6.0 Major Comp. List)
REV 10/20/06 (Appendix & parts lists)
REV. 04/10/07 (text)
MODEL E-1DBSL
DESCRIPTION
BEACON SAFETY SWITCH
40 uf 1kv CAP
3 uf 660V AC CAP
3 uf 660V AC CAP GE
CABINET SAFETY SWITCH
10 amp FUSE
1/8 amp FUSE
.5 amp FUSE
FLASHTUBE
DPDT OCTAL RELAY
SPDT OCTAL RELAY
5 SECOND TIME DELAY ON
RELEASE RELAY
BLEEDER RELAY
INDUCTOR
BURSTING CHOKE
METAL OXIDE VARISTOR
METAL OXIDE VARISTOR
15 POSITION PLUG
CONTROL PCB
SCHEMATIC TAG #
C103 - C109
C102
C101
CSS
F1
F2
F3
K5, K1, K7, K9
K4, K6, K8, K10, K12
K11
K2
L11
MOV2
MOV3
P1
PCB #1
