4300 WINDFERN RD. #100 HOUSTON TX 77041-8943
VOICE (713) 973-6905 FAX (713) 973-9352
WEB: twrlighting.com
D1LVS-T GPS CONTROLLER
ADDENDUM
NOTE
PLEASE READ
***IMPORTANT NOTICE***
This controller has been modified from a D1LVS to a
D1LVS-T GPS. The changes are as follows:
One (1)40 uF capacitor has been removed from this
controller and PCB#1 has been changed from a
STH01283 to a STH01285HK GPS.
Please adhere to these changes when servicing this unit.
FOR ADDITIONAL INFORMATION OR HELP, PLEASE CONTACT OUR
TECHNICAL SUPPORT GROUP AT (713) 973-6905 EXT 132, 136, OR 151.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D-1LVS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TWR Lighting D-1LVS

Summary of Contents for TWR Lighting D-1LVS

  • Page 1 4300 WINDFERN RD. #100 HOUSTON TX 77041-8943 VOICE (713) 973-6905 FAX (713) 973-9352 WEB: twrlighting.com D1LVS-T GPS CONTROLLER ADDENDUM NOTE PLEASE READ ***IMPORTANT NOTICE*** This controller has been modified from a D1LVS to a D1LVS-T GPS. The changes are as follows: One (1)40 uF capacitor has been removed from this controller and PCB#1 has been changed from a STH01283 to a STH01285HK GPS.
  • Page 2 D-1LVS SERIAL # PURCHASE DATE PURCHASED FROM C:\Documents and Settings\esalazar\Local Settings\Temporary Internet Files\OLK1\D-1LVS Rev 040903.doc 12/98; Rev. 6/99; Rev. 03/00; Rev. 05/00; Rev. 07/07/00 (dwg H01-226B); Reg. 07/08/00 (Pg. 9, DSI); Rev. 07/00 (o2L/H); Rev. 10/18/00 (retyped & o2-dwgs.) Rev. 05/14/01 (revised pg 1 – mounting width; warranty & return policy)

  • Page 3: Table Of Contents

    Flash Verified..................... 9 3.7.8 Strobe Fail Test ..................9 C:\Documents and Settings\esalazar\Local Settings\Temporary Internet Files\OLK1\D-1LVS Rev 040903.doc 12/98; Rev. 6/99; Rev. 03/00; Rev. 05/00; Rev. 07/07/00 (dwg H01-226B); Reg. 07/08/00 (Pg. 9, DSI); Rev. 07/00 (o2L/H); Rev. 10/18/00 (retyped & o2-dwgs.) Rev.
  • Page 4 RETURN POLICY ......................... 18 RETURN MERCHANDISE AUTHORIZATION FORM (RMA) ............ 19 C:\Documents and Settings\esalazar\Local Settings\Temporary Internet Files\OLK1\D-1LVS Rev 040903.doc 12/98; Rev. 6/99; Rev. 03/00; Rev. 05/00; Rev. 07/07/00 (dwg H01-226B); Reg. 07/08/00 (Pg. 9, DSI); Rev. 07/00 (o2L/H); Rev. 10/18/00 (retyped & o2-dwgs.) Rev.
  • Page 5 High Voltage Rectifier PCB #2 ................. H02-226A Relay PCB #3.......................H03-226 Strobe Beacon Detail ................... 100437i C:\Documents and Settings\esalazar\Local Settings\Temporary Internet Files\OLK1\D-1LVS Rev 040903.doc 12/98; Rev. 6/99; Rev. 03/00; Rev. 05/00; Rev. 07/07/00 (dwg H01-226B); Reg. 07/08/00 (Pg. 9, DSI); Rev. 07/00 (o2L/H); Rev. 10/18/00 (retyped & o2-dwgs.) Rev.

  • Page 6: Introduction

    APPLICATION The D-1LVS L-865 Controller is for use on lighting structures or towers that are approved to be lighted with Medium Intensity Strobes in accordance with the FAA’s Advisory Circular 70/7460-1K. Structures from 201' to 350' may be lighted with Medium Intensity lights.

  • Page 7: Installation

    Connect the RED wire from the photocell to TB1-6. 2.3.3 Connect the WHITE wire from the photocell to TB1-7. C:\Documents and Settings\esalazar\Local Settings\Temporary Internet Files\OLK1\D-1LVS Rev 040903.doc 3/8/2006 12/98; Rev. 6/99; Rev. 03/00; Rev. 05/00; Rev. 07/07/00 (dwg H01-226B); Reg. 07/08/00 (Pg. 9, DSI);...

  • Page 8: Power Wiring

    When installing multiple controllers together, the photocell is only required on one (1) unit. It can be installed on the master (or) slave. SSR interconnect wire must be common to all units. D2/3LV SSR TB3-2 / D-1LVS SSR TB1-6. POWER WIRING...
  • Page 9 D-1LVS CONTROLLER C:\Documents and Settings\esalazar\Local Settings\Temporary Internet Files\OLK1\D-1LVS Rev 040903.doc 3/8/2006 12/98; Rev. 6/99; Rev. 03/00; Rev. 05/00; Rev. 07/07/00 (dwg H01-226B); Reg. 07/08/00 (Pg. 9, DSI); Rev. 07/00 (o2L/H); Rev. 10/18/00 (retyped & o2-dwgs.) Rev. 05/14/01 (revised pg 1 – mounting width; warranty & return policy) Rev 03/20/03 (TWR logo –...

  • Page 10: Lighting Kit Wiring

    Controller should be in the daymode of operation when performing this test. Check status of operation. Turn SW3 on or cover the photocell and alarm C:\Documents and Settings\esalazar\Local Settings\Temporary Internet Files\OLK1\D-1LVS Rev 040903.doc 3/8/2006 12/98; Rev. 6/99; Rev. 03/00; Rev. 05/00;...

  • Page 11: Controller Configuration

    Connect at least an18/20 gauge wire from master unit D2/3LV PCB 1-15 (TS) to slave unit D2/3LV PCB1 P1-15 (TS) or D-1LVS PCB1 P1-15 (TS). 2.7.2 Connect at least an 18/20 gauge wire (ground) from one chassis to the other chassis.

  • Page 12: Theory Of Operation

    Meanwhile, the storage capacitor is being recharged by the transformer and the high voltage rectifier. C:\Documents and Settings\esalazar\Local Settings\Temporary Internet Files\OLK1\D-1LVS Rev 040903.doc 3/8/2006 12/98; Rev. 6/99; Rev. 03/00; Rev. 05/00;...
  • Page 13 D-1LVS CONTROLLER C:\Documents and Settings\esalazar\Local Settings\Temporary Internet Files\OLK1\D-1LVS Rev 040903.doc 3/8/2006 12/98; Rev. 6/99; Rev. 03/00; Rev. 05/00; Rev. 07/07/00 (dwg H01-226B); Reg. 07/08/00 (Pg. 9, DSI); Rev. 07/00 (o2L/H); Rev. 10/18/00 (retyped & o2-dwgs.) Rev. 05/14/01 (revised pg 1 – mounting width; warranty & return policy) Rev 03/20/03 (TWR logo –...

  • Page 14: Timing Circuit

    When the AC line voltage is turned off, relays close allowing the resistors to discharge the high voltage stored in the capacitor bank below 50V in 30 seconds. C:\Documents and Settings\esalazar\Local Settings\Temporary Internet Files\OLK1\D-1LVS Rev 040903.doc 3/8/2006 12/98; Rev. 6/99; Rev. 03/00; Rev. 05/00;...

  • Page 15: Strobe Diagnostic Circuits

    R30 and LED6 (D20). Under normal circumstances, the red LED should be at full intensity indicating voltage to be normal. An absence of this indication means that the voltage is no longer present. C:\Documents and Settings\esalazar\Local Settings\Temporary Internet Files\OLK1\D-1LVS Rev 040903.doc 3/8/2006 12/98; Rev. 6/99; Rev. 03/00; Rev. 05/00;...

  • Page 16: Nightmode

    Switch S1, when turned on, cuts off the timing signal to the trigger circuit and illuminates LED2 (D25). At this time a strobe alarm should be received at J2. The normal position of S1 is off (switch upward). C:\Documents and Settings\esalazar\Local Settings\Temporary Internet Files\OLK1\D-1LVS Rev 040903.doc 3/8/2006 12/98; Rev. 6/99; Rev. 03/00; Rev. 05/00;...

  • Page 17: Trouble Shooting

    Observe at this time the LEDs located on PCB #1 and PCB #2. Determine by observation of these LED indicators if the controller is performing to normal operation. C:\Documents and Settings\esalazar\Local Settings\Temporary Internet Files\OLK1\D-1LVS Rev 040903.doc 3/8/2006 12/98; Rev. 6/99; Rev. 03/00; Rev. 05/00;...

  • Page 18: Trouble Shooting Assistance

    Observe the status of the timing LED. If the LED is dim or out completely, check LED9, if dim or out, replace PCB #1. If one or both are lit, you should have timing. C:\Documents and Settings\esalazar\Local Settings\Temporary Internet Files\OLK1\D-1LVS Rev 040903.doc 3/8/2006 12/98; Rev. 6/99; Rev. 03/00; Rev. 05/00;...

  • Page 19: False Or Nonexistent Beacon Alarms

    #1). When this switch is in the alarm test mode, the test mode indicator (LED2) will be illuminated or blinking slightly. C:\Documents and Settings\esalazar\Local Settings\Temporary Internet Files\OLK1\D-1LVS Rev 040903.doc 3/8/2006 12/98; Rev. 6/99; Rev. 03/00; Rev. 05/00;...

  • Page 20: Maintenance Guide

    No scheduled maintenance is required. Perform on an as needed basis only. PHOTOCELL The photocell is a sealed unit. No maintenance is needed or required other than C:\Documents and Settings\esalazar\Local Settings\Temporary Internet Files\OLK1\D-1LVS Rev 040903.doc 3/8/2006 12/98; Rev. 6/99; Rev. 03/00; Rev. 05/00;...
  • Page 21 D-1LVS CONTROLLER replacement as necessary. C:\Documents and Settings\esalazar\Local Settings\Temporary Internet Files\OLK1\D-1LVS Rev 040903.doc 3/8/2006 12/98; Rev. 6/99; Rev. 03/00; Rev. 05/00; Rev. 07/07/00 (dwg H01-226B); Reg. 07/08/00 (Pg. 9, DSI); Rev. 07/00 (o2L/H); Rev. 10/18/00 (retyped & o2-dwgs.) Rev. 05/14/01 (revised pg 1 – mounting width; warranty & return policy) Rev 03/20/03 (TWR logo –...

  • Page 22: Major Components Parts List

    STJ01004 ISOLATION TRANSFORMER STC05004 STC30018 FERRORESONANT C:\Documents and Settings\esalazar\Local Settings\Temporary Internet Files\OLK1\D-1LVS Rev 040903.doc 3/8/2006 12/98; Rev. 6/99; Rev. 03/00; Rev. 05/00; Rev. 07/07/00 (dwg H01-226B); Reg. 07/08/00 (Pg. 9, DSI); Rev. 07/00 (o2L/H); Rev. 10/18/00 (retyped & o2-dwgs.) Rev. 05/14/01 (revised pg 1 – mounting width; warranty & return policy) Rev 03/20/03 (TWR logo –...
  • Page 23 STROBE BEACON LENS STDBCLENS BEACON GASKET STBEAGSK2 C:\Documents and Settings\esalazar\Local Settings\Temporary Internet Files\OLK1\D-1LVS Rev 040903.doc 3/8/2006 12/98; Rev. 6/99; Rev. 03/00; Rev. 05/00; Rev. 07/07/00 (dwg H01-226B); Reg. 07/08/00 (Pg. 9, DSI); Rev. 07/00 (o2L/H); Rev. 10/18/00 (retyped & o2-dwgs.) Rev.

  • Page 24: Recommended Spare Parts List

    1/2 amp FUSE X9KE SPDT RELAY X99KE DPDT RELAY C:\Documents and Settings\esalazar\Local Settings\Temporary Internet Files\OLK1\D-1LVS Rev 040903.doc 3/8/2006 12/98; Rev. 6/99; Rev. 03/00; Rev. 05/00; Rev. 07/07/00 (dwg H01-226B); Reg. 07/08/00 (Pg. 9, DSI); Rev. 07/00 (o2L/H); Rev. 10/18/00 (retyped & o2-dwgs.) Rev.
  • Page 34 632X14PHH 6-32 X 1/4 PH PH SCREW =ITEMS NOT SHOWN ASSEMBLY VIEW NOTE: 1. ITEM #20A-#20G SOLD AS AN ASSEMBLY ONLY. ORDER ITEM PART #STBFRAMKIT. TWR Lighting, Inc. DRAWN jbustamante 7/26/2007 CHECKED Enlightened Technology TITLE L-865 STROBE BEACON ASSEMBLY DETAIL...
