5. Operation

5.1 Display and Control Buttons

CLAMP START STOP WINDOW CLAMP
CLAMP
START
STOP
WINDOW
• Clamp Buttons in the Left and Right provide the exactly same function. They
are provided for the convenience to press the button by the bare hand without
holding the lens.
• Be sure that Lens Position Button only works during Roughing process. It is
useful to adjust the lens position if the lens exceeds the wheel range because
of the thickness.
Open/Close Clamp (Lens Position Left/Right)
Start Edging
Stop Edging
Open/Close Edging Room Window
! NOTE
Touch Screen
