Show warning message when you delete hole data.
• Hole Data Loading Type
Select hole data loading method
• Use Hole Data Preset
Show hole data preset buttons in the hole editor screen
• Confirm preset load
Show confirm message box when you load hole data preset
• Use Demo Lens Curve (Automatic correction of hole position)
Apply demo lens curve value for drilling
• Default Demo Lens Curve
Set default demo lens curve value
• Drill Bit Warning Message
Show warning message when the diameter of the hole is smaller than the
drill bit.
• Automatic correction of hole position
If the curvature of lens is different from that of demo lens, the distance of hole
from lens edge can be longer or shorter than desired.
Automatic correction of hole position is a function which compensate drilling hole
position automatically by comparing curvatures of demo lens and actual lens.
