1
-------------------------------------------------------------------- HDC-7000 Opreator's Manual
Operator's Manual
HDC-7000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDC-7000 and is the answer not in the manual?

Questions and answers

Vinny Vitiritto
March 7, 2025

Hi, my name is Vinny Vitiritto, I work for an MSP that is currently swapping out computers for a client (Optical Gallery Arizona). One of the computers is connected to an HDC-7000 and we are unable to find the installation cd anywhere. Is there a chance you can send us the installer for the software related to this device? Thank you!

0

Subscribe to Our Youtube Channel

Related Manuals for Huvitz HDC-7000

Summary of Contents for Huvitz HDC-7000

  • Page 1 -------------------------------------------------------------------- HDC-7000 Opreator’s Manual Operator’s Manual HDC-7000...
  • Page 2 HUVITZ reserves the right to make changes in its products or product specifications at any time and without prior notice, and is not required to update this documentation to reflect such changes.

  • Page 3: Table Of Contents

    -------------------------------------------------------------------- HDC-7000 Opreator’s Manual CONTENTS Introduction ......................5 1.1. Outline of product ....................5 1.2. Classifications ....................5 Safety Information ....................6 2.1. Introduction......................6 2.2. Safety Symbols....................7 2.3. Environmental factors ..................8 2.4. Safety Precautions ....................9 Features ......................... 11 3.1. Organization ....................12 3.1.1. Remote Controller ................12 3.1.2.
  • Page 4 HDC-7000 Operator’s Manual ----------------------------------------------------------------------- 5.3. User Menu Operation..................32 5.4. Check Version Info...................45 Keeping and Maintenance..................46 6.1. Keeping ......................46 6.2. Maintenance ....................46 6.2.1. Replacing the Battery of Chart Remote..........46 Specifications ......................47 Components List ....................48 8.1. Standard accessories..................48 8.2. Optional accessories ..................49...

  • Page 5: Introduction

    1.1. Outline of product HUVITZ HDC-7000 is an automatic digital chart which provides 41 different charts for the eye optometry. Users can select the desired charts instantaneously by cordless remote controller. Charts move quickly and quietly. The customized two programs will help you to perform more convenient and effective examination.

  • Page 6: Safety Information

    HDC-7000 Operator’s Manual ----------------------------------------------------------------------- 2. Safety Information 2.1. Introduction Safety is everyone’s responsibility. The safe use of this equipment is largely dependent upon the installer, user, operator, and maintainer. It is imperative that personnel study and become familiar with this entire manual before attempting to install, use, clean, service or adjust this equipment and any associated accessories.

  • Page 7: Safety Symbols

    -------------------------------------------------------------------- HDC-7000 Opreator’s Manual 2.2. Safety Symbols The International Electrotechnical Commission (IEC) has established a set of symbols for medical electronic equipment, which classify a connection or warn of any potential hazards. The classifications and symbols are shown below. Save these instructions I and O on the power switch represent ON and OFF respectively.

  • Page 8: Environmental Factors

    HDC-7000 Operator’s Manual ----------------------------------------------------------------------- 2.3. Environmental factors Avoid the following environments for operation or storage: Where the equipment is exposed to water vapor. Don’t operate an equipment with a wet hand. Where the equipment is exposed to direct sunlight. Where the temperature changes extremely.

  • Page 9: Safety Precautions

    The equipment must be operated only by, or under direct supervision of a properly trained and qualified person. Customer maintenance of this equipment may only be performed as stated in the User’s Manual. Any additional maintenance may only be performed by HUVITZ service technicians or other authorized persons.
  • Page 10 HDC-7000 Operator’s Manual ---------------------------------------------------------------------- The manufacturer is only responsible for effects on safety, reliability, and performance of this equipment when the following requirements are fulfilled: (1) The electrical installation in the respective room corresponds to the specifications stated in this manual and (2) This equipment is used, operated, and maintained according to this manual.

  • Page 11: Features

    Using HDC-7000, you can test patient’s vision within 8~20 feet (2.5~6m). The distance can be adjusted by 0.5 feet (when using meter, 0.1m). If you want to install HDC-7000 in smaller distance than 8 feet, you can use mirror. Red/Green color adjustment Red/Green color can be adjusted to your red/green filter.

  • Page 12: Organization

    HDC-7000 Operator’s Manual ---------------------------------------------------------------------- 3.1. Organization 3.1.1. Remote Controller ○ 1 ○ ○ ○ ○ ○ ○ ○ ○ ○ ○...
  • Page 13 -------------------------------------------------------------------- HDC-7000 Opreator’s Manual ① Chart selection buttons Select a chart for optometry ② Program left, right buttons Move previous (left) or next (right) chart on programmed chart display. ③ Program selection buttons Select program1 or program2 ④ Contrast button Change the contrast level of chart.

  • Page 14: Ir, Can Receiver

    HDC-7000 Operator’s Manual ---------------------------------------------------------------------- 3.1.2. IR, CAN Receiver ○ 1 ○ ○ ① IR receive area There is IR receive sensor. ② CAN connector This connector is connected with Junction Box on CAN communication. ③ USB port Connect with PC...

  • Page 15: System Requirement

    -------------------------------------------------------------------- HDC-7000 Opreator’s Manual 3.1.3. System Requirement HDC-7000 must be installed the system, referred below. Operating System Windows 2000, Windows XP, Windows Vista Recommended PC Specification PC, recommended by Operation System, with USB port Required HDD space Above 100MB Display Device...

  • Page 16: Preparation Before Using

    Software Installation Step 1. Running Setup Program HDC-7000 setup program will automatically start by auto-run when you insert the installation CD into CD-ROM on PC. If it doesn’t work or is installing from local network drive, open the installation folder and manually run HDC-...
  • Page 17 -------------------------------------------------------------------- HDC-7000 Opreator’s Manual Step 2. Start setup Click ‘Next’ Button. Step 3. End User License Agreement After reading End User License Agreement, click ‘I Agree’, then click ‘Next’.
  • Page 18 HDC-7000 Operator’s Manual ---------------------------------------------------------------------- Step 4. Select Install folder and Install If you want to install HDC-7000 SW to another folder, click ‘Browse’ button and select the folder where you want. If you want to install on default folder, skip this process.
  • Page 19 -------------------------------------------------------------------- HDC-7000 Opreator’s Manual Step 5. Installation Complete. Click ‘OK’ button...

  • Page 20: Ir/Can Receiver Installation And Connection

    HDC-7000 Operator’s Manual ---------------------------------------------------------------------- 4.2. IR/CAN Receiver Installation and Connection Step 1. Install Driver Run CDM 2.04.06.exe in served CD. Running screen is as follows. Step 2. Connect IR/CAN Receiver Connect IR/CAN Receiver to USB port.

  • Page 21: Check Remote Controller

    -------------------------------------------------------------------- HDC-7000 Opreator’s Manual 4.3. Check Remote Controller Put the batteries into remote controller. 4.4. Configuration Configure the options which are suitable to installation environment. Refer ‘5.3 User Menu Operation’ for details.

  • Page 22: Operation

    HDC-7000 Operator’s Manual ---------------------------------------------------------------------- 5. Operation 5.1. Mask operation Buttons used on masking...
  • Page 23 -------------------------------------------------------------------- HDC-7000 Opreator’s Manual Horizontal masking [Figure 1] Horizontal masking 1) To enter the horizontal masking mode, press up, down, or horizontal masking button. 2) To move mask, press up or down button. 3) When the masking row is top row and you press up button or the masking row is bottom and you press down button, you can see next page with horizontal masking.
  • Page 24 HDC-7000 Operator’s Manual ---------------------------------------------------------------------- Vertical maksing [Figure 2] Vertical masking 1) To enter the vertical masking mode, press left or right button. 2) If you press up or down button, you can see previous or next chart with vertical masking.
  • Page 25 -------------------------------------------------------------------- HDC-7000 Opreator’s Manual point masking [Figure 3] point masking 1) To enter the point masking mode, press point masking button. (left top optotype will be displayed.) 2) If you press up or down button, next point masking optotype will be displayed.

  • Page 26: Descriptions Of Charts For The Measuring Of Binocular Visual Functions

    HDC-7000 Operator’s Manual ---------------------------------------------------------------------- 5.2. Descriptions of Charts for the Measuring of Binocular Visual Functions Schober Chart -. Objective: To execute a phoria test during the subjective test. -. Auxiliary Lens: Red Filter (right), Green Filter (left), Binocular Rotary Prism -.
  • Page 27 -------------------------------------------------------------------- HDC-7000 Opreator’s Manual Worth 4 Dots Chart -. Objective: To find suppression during the subjective test. It is possible to check the internal or external phoria. -. Auxiliary Lens: Red Filter (right), Green Filter (left) -. Expectation: To check how many dots can be seen. Normally, 4 points are seen.
  • Page 28 HDC-7000 Operator’s Manual ---------------------------------------------------------------------- Binocular Balance Chart -. Objective: To adjust binocular balance during the subjective test -. Auxiliary Lens: Red Filter (right), Green Filter (left) -. Expectation: The upper row for the right eye and the lower row for the left eye appear to be similarly clear.
  • Page 29 -------------------------------------------------------------------- HDC-7000 Opreator’s Manual Cross Chart with the Fixation Point -. Objective: To execute the phoria test during the subjective test. -. Auxiliary Lens: Red Filter (right), Green Filter (left) -. Expectation: The upper-right cross mark for the right eye and the lower-left cross mark for the left eye are overlapped into one ideal cross.
  • Page 30 HDC-7000 Operator’s Manual ---------------------------------------------------------------------- Horizontal Coincidence Chart -. Objective: To execute the Coincidence and the horizontal phoria test during the subjective test. -. Auxiliary Lens: Red Filter (right), Green Filter (left) -. Expectation: The upper frame for the right eye and the lower frame for the left eye form a ideal square.
  • Page 31 -------------------------------------------------------------------- HDC-7000 Opreator’s Manual Stereo Chart -. Objective: To execute the Stereo test during the subjective test. -. Auxiliary Lens: Red Filter (right), Green Filter (left) -. Expectation: The upper rod for the right eye appears to be closer to the patient than the lower rod for the left eye.

  • Page 32: User Menu Operation

    5.3. User Menu Operation HDC-7000 provides user menu to convert settings according to installation environment. In user menu, you can adjust communication channel of cordless remote controller, testing distance, LCD type, notation of Visual Acuity and red/green color. You can see the user menu using ‘MENU’...
  • Page 33 -------------------------------------------------------------------- HDC-7000 Opreator’s Manual Communication Channel HDC-7000 has 4-communication channel. HDC-7000 is operated by only the remote controller which has same communication channel. So, Four HDC-7000’s can be installed in one refraction room without mutual interference. You can convert communication as follows.
  • Page 34 HDC-7000 Operator’s Manual ---------------------------------------------------------------------- Testing Distance HDC-7000 display optotypes with different size according to the testing distance. So testing distance must be selected correctly. You can convert testing distance as follows. Press the ‘MENU’ button to display user menu. Select testing distance which correspond to HDC-7000 installation environment, then click ‘OK’...
  • Page 35 -------------------------------------------------------------------- HDC-7000 Opreator’s Manual LCD type and resolution HDC-7000 support various LCD monitors: 17”, 19”, 20.1”, 23” and 24”. Because different LCD has different size of displayed image that has same pixel size, it is very important to select LCD type. You can convert LCD type as follows.
  • Page 36 HDC-7000 Operator’s Manual ---------------------------------------------------------------------- Notation of Visual Acuity In HDC-7000, you can convert notation of visual acuity. Decimal format like 1.0, 2.0 is default setting. You can change this to Snellen fraction using feet like 20/20, 20/10 or using meter like 6/6 or 6/3. You can convert notation as follows.
  • Page 37 -------------------------------------------------------------------- HDC-7000 Opreator’s Manual Random Optotype Display HDC-7000 provides random prototype display. This gives better reliability to the optometry. (Generally, chart displays same optotypes at the same position. So patient can remember some optotypes. This makes optometry to have less reliability). You can convert this configuration as follows.
  • Page 38 HDC-7000 Operator’s Manual ---------------------------------------------------------------------- Mirror function HDC-7000 provides revert-optotype display. When HDC-7000 is installed with distance below 2.5m (or 8ft.), you can use mirror with this option to obtain adequate test distance. You can convert this configuration as follows Press the ‘MENU’ button to display user menu.
  • Page 39 -------------------------------------------------------------------- HDC-7000 Opreator’s Manual Register to Start program HDC-7000 can be registered as startup program. This makes HDC-7000 starts automatically when windows start. You can convert this configuration as follows. Press the ‘MENU’ button to display user menu. Select ‘Yes’ or ‘No’ which you want, then click ‘OK’ button. If you use remote controller, you can select ‘Yes’...
  • Page 40 HDC-7000 Operator’s Manual ---------------------------------------------------------------------- Image change time in Image Gallery You can convert image auto change time in Image Gallery mode. If you set ‘Change Time’ to 0, auto change is not worked. You can convert this configuration as follows.
  • Page 41 -------------------------------------------------------------------- HDC-7000 Opreator’s Manual Monitor select in mutil-monitor environment In multi-monitor environment, HDC-7000 can select default output device. When you use only one monitor, this setting will be disabled. You can adjust red/green color as follows. Press the ‘MENU’ button to display user menu.
  • Page 42 Red/Green Color Because HDC-7000 support various LCD monitors, there color of green, red might be different even if RGB value is same. To solve this problem, HDC-7000 provides color adjusting function. You can adjust red/green color as follows. Press the ‘MENU’ button to display user menu.
  • Page 43 -------------------------------------------------------------------- HDC-7000 Opreator’s Manual Click ‘Color Adjusting >>’. If you use remote controller, you can select ‘Color Adjusting >>’ by pressing mask left, right button. Press point mask button to enter Color adjusting menu. Using mouse on left-bottom color box, adjust red or green color. You can preview on right-bottom box.
  • Page 44 HDC-7000 Operator’s Manual ---------------------------------------------------------------------- ‘Wavelength adjusting’ is used to adjust red & green background color. If you don’t want apply converted settings, Click ‘Cancel’. If you use remote controller, press ‘MENU’ button.

  • Page 45: Check Version Info

    -------------------------------------------------------------------- HDC-7000 Opreator’s Manual 5.4. Check Version Info You can check version info of HDC-7000 with the following procedure. 1) Connect the mouse. 2) Click right mouse button to display menu. 3) Select ‘About’. After you select ‘About’, you can see following figure.

  • Page 46: Keeping And Maintenance

    HDC-7000 Operator’s Manual ---------------------------------------------------------------------- Keeping and Maintenance 6.1. Keeping Keep product to the place which is suitable to ‘2.3 Environmental factors’ and ‘2.4 Safety precautions’. 6.2. Maintenance 6.2.1. Replacing the Battery of Chart Remote Remove the battery cover from the rear panel by sliding it.

  • Page 47: Specifications

    -------------------------------------------------------------------- HDC-7000 Opreator’s Manual Specifications Chart 41charts -34 mask, Red/green Filters Mask Horizontal, Vertical, Single optotype display Red/Green chart Color adjustable Test distance 8~20 feet (2.5~6m), adjustable by 0.5 feet (0.1m) Applicable 17, 19, 20, 23, 24-inch LCD monitor monitor...

  • Page 48: Components List

    HDC-7000 Operator’s Manual ---------------------------------------------------------------------- Components List 8.1. Standard accessories ① Cordless remote controller ② HDC-7000 installation CD ③ USB cable ④ IR/CAN receiver ⑤ User manual...

  • Page 49: Optional Accessories

    -------------------------------------------------------------------- HDC-7000 Opreator’s Manual 8.2. Optional accessories Wall mount (only for iMac)

  • Page 50: Service Information

    If you can’t contact with your local distributor, you can directly get in touch with the service department of the HUVITZ using the phone number and the address written in the below table. How to Contact HUVITZ Co., Ltd...
