Table 26. Microsd Card Connector Cn9 - ST STM32F107Series User Manual

UM0896
Table 26.
Pin
1
2
3
4
5
www.BDTIC.com/ST
MicroSD Card connector CN9
Description
NC
CS_SDcard (PE7)
MOSI (SPI
+3.3 V
SCK (SPI
Doc ID 17009 Rev 2
Pin number
6
7
- PA7) 8
1
9
- PA5) 10
1
Connectors
Description
GND
MISO (SPI - PA6)
1
NC
GND
SD_detect (PA4)
