General Purpose 5-Way Joystick Sw1; Leds; Spi Bus Communication; Table 7. Joystick Direction Mapping - ST STM32F107Series User Manual

Configuration
5.3

General purpose 5-way joystick SW1

A 5-way general purpose joystick is available on the top side of the board.
Table 7.
5.4

LEDs

4 general purpose LEDs (LD1-LD4) are available on the top side of the board. All LEDs are
switched on when the related GPIO pin is driven low.
Table 8.
5.5

SPI bus communication

SPI signals are connected to the MEMS connector, Wi-Fi module and PLM. Use carefully
the signal enable of the listed devices to select only one at a time. SPI signals can be also
configured as analog inputs of the STM32 microcontroller ADC for optionally attached
analog MEMS module. Please refer to
