UM0896
2
5.6 I C, USART signals branching for MEMS, Wi-Fi, digital audio

and PLM

Table 9.
Jumper
JP2
(3-pin resistor)
JP3
(3-pin resistor)
Table 10.
Jumper
JP6
(3-pin resistor)
JP7
(3-pin resistor)
www.BDTIC.com/ST
2
MEMS, Wi-Fi, PLM I C and USART signals branching
PB7 is connected to MEMS extension connector as
2
I C SDA. The jumper must be set as shown:
PB7 is connected as USART1_RX to Wi-Fi 2
position 10 and PLM.
The jumper must be set as shown:
PB6 is connected to MEMS extension connector as
2
I C SCL.
The jumper must be set as shown:
PB6 is connected as USART1_TX to Wi-Fi 2
position 10 and PLM.
The jumper must be set as shown:
2
Digital audio I C branching
2
I C SDA is connected to DAC_FTM2 signal of CN3
(audio).
The jumper must be set as shown:
GPIO PE0 is connected to DAC_FTM2 signal of
CN3 (audio).
The jumper must be set as shown:
2
I C SCL is connected to DAC_FTM1 signal of CN3
(audio).
The jumper must be set as shown:
GPIO PE1PB6 is connected to DAC_FTM1 signal of
CN3 (audio).
The jumper must be set as shown:
Doc ID 17009 Rev 2
Description
Description
Configuration
Configuration
Configuration
13/43
