Rinnai Symmetry RDV3611 Operation Manual
Hide thumbs
Also See for Symmetry RDV3611:
- Installation manual (28 pages) ,
- Operation manual (20 pages) ,
- Maintenance instructions manual (20 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Related Manuals for Rinnai Symmetry RDV3611
Summary of Contents for Rinnai Symmetry RDV3611
- Page 1 Symmetry RDV3611 gas fireplace Operation guide...
- Page 2 Important Appliance must be installed with a Rinnai approved flue system. This appliance must be installed in accordance with: - Manufacturer’s installation instructions - AS/NZS 5601 Gas Installations - AS/NZS 5263 Gas appliances standards For use with Natural Gas or Universal LPG as indicated on the appliance.
-
Page 3: Table Of Contents
Installation checklist, and installer details .....16 Purchase details, and warranty registration ..17 Limited Warranty ..........18 Servicing Gas fires, like cars, require regular maintenance and servicing. For reliable operation Rinnai gas fires should be serviced every two years, including inspection of the flue system. -
Page 4: Safety
This must be Most contain butane gas which a genuine replacement part can be a fire hazard if used available from Rinnai. near the appliance. 4 | Symmetry RDV3611 operation guide: 11158-C 03-20... -
Page 5: About Your Rinnai Symmetry Gas Fire
About your Rinnai Symmetry gas fire Congratulations on the purchase of your Rinnai gas fire. We hope you love this product as much as we do, and on the off chance that something does go wrong, or if you need help, we’re only a phone call away. -
Page 6: General Information
PCB etc. Consult a qualified electrician if direct wiring is required as it must comply with AS/NZS 5601 and AS/NZS 3000 and other relevant local regulations 6 | Symmetry RDV3611 operation guide: 11158-C 03-20... -
Page 7: Symmetry Operation
The controller when operating in any of the three modes will automatically shutdown and switch the fire off if the room temperature exceeds 40 °C for more than three minutes— this is a safety feature. Symmetry RDV3611 operation guide: 11158-C 03-20 | 7... -
Page 8: Wireless Controller
If the LED on the fire is off, check the flame symbol on the controller. If it is pulsing, the fire is still on and will relight when the room temperature drops. 8 | Symmetry RDV3611 operation guide: 11158-C 03-20... -
Page 9: Wireless Controller Display
Indicates the time and day of the UP/DOWN changes hours, minutes or temperature. week programming. Press and hold for two seconds. OK accepts the current function and advances to the next function Symmetry RDV3611 operation guide: 11158-C 03-20 | 9... -
Page 10: Controller Modes Of Operation
Flame setting Flame symbol will correspond to the flame setting selected—F7-F1 (highest to lowest). Flame mode Nothing will be displayed in this window when operating in flame mode. 10 | Symmetry RDV3611 operation guide: 11158-C 03-20... -
Page 11: Programming Your Controller
1, you can reduce the temperature setting using the DOWN button until --°C is reached. This means no set temperature has been programmed and the fire will stay off until the next period setting. Symmetry RDV3611 operation guide: 11158-C 03-20 | 11... -
Page 12: Operation Using The Controller
The fire first lights to pilot, then after a period switches to the high setting. To turn off, press and release the PWR button. 12 | Symmetry RDV3611 operation guide: 11158-C 03-20... -
Page 13: Operation Without The Controller
Turning the fire off ON/OFF button Press the On/Off button once. The LED power indicator Blue LED indicator will turn off. Increase LED indicators Decrease • = blue • Standby = red • = nothing Symmetry RDV3611 operation guide: 11158-C 03-20 | 13... -
Page 14: Troubleshooting
Press the On/Off button on the control panel isn’t going and the controller once, the LED will flash, press again the LED doesn’t work will stay on and the fire will attempt to re-ignite. The controller should work now. 14 | Symmetry RDV3611 operation guide: 11158-C 03-20... -
Page 15: Abnormal Flame Pattern
Abnormal flame pattern Each Rinnai flame fire has a distinct flame pattern. This should look the same every time you start your fire, after an initial warm up period of approximately 20 minutes. Abnormal flame performance and/or pattern can indicate a problem with your fire, such as blocked gas injectors, or shifting of burn media. -
Page 16: Installation Checklist, And Installer Details
Checklist F Appliance positioned in a suitable location (clearances, mantels, surrounds etc.). F Rinnai flue system installed and tested to ensure effective draw. F Gas pressure checked and set according to the data plate. F Burn media installed as per instructions. -
Page 17: Purchase Details, And Warranty Registration
Warranty claim To make a warranty claim, contact Rinnai on 0800 RINNAI (0800 746 624) or email info@rinnai.co.nz. Symmetry RDV3611 operation guide: 11158-C 03-20 | 17... -
Page 18: Limited Warranty
Rinnai brings you peace of mind with a: 5-year firebox warranty This warranty is applicable to all Rinnai gas fires manufactured from 01 May 2019. All terms of the warranty, subject to the conditions below, are effective from the date of first installation. The attending service person reserves the right to verify this by requesting a copy of the gas certificate of compliance prior to commencement of any warranty work. - Page 19 8. Rinnai reserves the right to have installed product returned to the factory for inspection. 9. Where the gas fire is installed outside the metropolitan area or further than 40 km from a Rinnai authorised service centre, travel costs shall be the owner’s responsibility.
- Page 20 Rinnai.co.nz 0800 746 624 http://www.youtube.com/rinnainz http://www.facebook.com/rinnainz Serial number Symmetry RDV3611 operation guide:11158-C...
