Rinnai 650 Gas Fire (RDV600ER)
Rinnai 750 Gas Fire (RDV700ER)
Gas Fireplace
Operation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Rinnai 650 and is the answer not in the manual?

Questions and answers

Summary of Contents for Rinnai Rinnai 650

  • Page 1 Models: Rinnai 650 Gas Fire (RDV600ER) Rinnai 750 Gas Fire (RDV700ER) Gas Fireplace Operation Manual...
  • Page 2 Congratulations on the purchase of your Rinnai 650 or 750 Gas Fire. We trust you will have many years of comfort and enjoyment from your appliance. BEFORE USING THIS APPLIANCE Before proceeding with the operation or installation read this manual thoroughly and gain a full IMPORTANT understanding of the appliance, to ensure safe and correct use.
  • Page 3: Table Of Contents

    Error Codes ������������������������������������������������������������������������������������������������������������������������������������������������������������������������ 12 Cleaning ����������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 13 Normal Operational Characteristics �������������������������������������������������������������������������������������������������������������������������������� 13 Trouble Shooting ��������������������������������������������������������������������������������������������������������������������������������������������������������������� 13 Trouble Shooting Checklist ���������������������������������������������������������������������������������������������������������������������������������������������� 14 Service �������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 14 Abnormal Flame Pattern ��������������������������������������������������������������������������������������������������������������������������������������������������� 15 CR2450 Button Batteries ��������������������������������������������������������������������������������������������������������������������������������������������������� 15 Installation Checklist Installation Record Contacts Rinnai RHFE0800F_1000_1500 OM...
  • Page 4: Warnings & Important Information

    For safety and warranty purposes, appliances that may be damaged or incorrect must not be installed or operated under any circumstances. Installation of damaged or incorrect appliances may contravene local government regulations. Rinnai disclaims any liability or responsibility whatsoever in relation to the installation or operation of damaged or incorrect appliances.
  • Page 5: Modifications

    Flue terminal MUST always vent directly to outdoors. DO NOT extend the flue vertically or horizontally in ways other than prescribed in this appliance manufacturer’s installation instructions. ONLY the flue components specified by Rinnai MUST be used. When considering installation ensure minimum clearances as follows are adhered to, refer Fig.
  • Page 6: Operational Safety Warnings

    When the heater is operated for the first time or after long periods of non use a slight odour may be emitted, this is normal. However if odours persist switch ‘OFF’ the appliance and contact Rinnai. Young children should be supervised at all times. Hand or body contact with the warm air discharge louvres and glass must be avoided.
  • Page 7: Safety Devices

    These devices within the appliance automatically cut of the gas supply to the burners in the event of a flame failure. Refer to the “CARE AND MAINTENANCE” pages; 12 through 15 for further information. Pressure Relief The burner box glass panel is secured to the burner box via spring loaded pressure relief fasteners. Rinnai RDV 600_700ER OM...
  • Page 8: About Your Heater

    See "Remote Control Operation" on page 10. Flame Up / Down See "Remote Control Operation" on page 10. buttons: Room temperature Displays the current temperature of the room in which the control is located. display See "Remote Control Operation" on page 10. Rinnai RDV 600_700ER OM...
  • Page 9: Control Panel Operation

    The heater will automatically modulate between flame settings to maintain the default set temperature of 22°C. No additional control of the flame or heat output is possible via the appliance ON/OFF button. Rinnai RDV 600_700ER OM...
  • Page 10: Remote Control Operation

    NOTE Refer to "Control Panel Operation" on page 9 for details on how to use the appliance in this mode and the limitations of this form of operation. Rinnai RDV 600_700ER OM...
  • Page 11: Battery Safety

    Noting that 0X (OK) will briefly be shown on the digital display to confirm that the batteries have been successfully replaced. Remember to dispose of used button batteries immediately and safely. IMPORTANT Rinnai RDV 600_700ER OM...
  • Page 12: Care & Maintenance

    Service call. The appliance is fitted with an overheat safety switch which will shut off the appliance. If the appliance shuts off repeatedly servicing or inspection of the flue for may be required, contact Rinnai for advice. Rinnai RDV 600_700ER OM...
  • Page 13: Cleaning

    If ignition does not occur the unit will switch off automatically. Try operating the heater again if this occurs, if this continues however then contact Rinnai for advice. The heater may make noises after ignition or switching off. This is due to the expansion and contraction of the internal components and is normal.
  • Page 14: Trouble Shooting Checklist

    If the power supply cord or any other component of the heater are damaged, they MUST BE replaced by Rinnai or a suitably qualified person. Rinnai has a Service and Spare Parts network with personnel who are fully trained and equipped to give the best service on your Rinnai appliance.
  • Page 15: Abnormal Flame Pattern

    ABNORMAL FLAME PATTERN Each Rinnai Gas Fire has a distinct flame pattern. The flame should look the same every time you operate your heater, after an initial warm up period of approximately 15 minutes. Abnormal flame performance and/or pattern can indicate a problem with your heater, such as blocked gas injectors, incorrectly installed / inadequate flue system or the Ceramic logs / stones and/or burner media may have shifted from when the heater was first installed.
  • Page 16: Installation Checklist

    Is the appliance positioned in a suitable location (clearances, combustible clearances, mantels and surrounds etc.)? 2. Was a Rinnai approved flue system installed and tested in accordance with the instructions? 3. Has the gas pressure been checked and set? 4. Has the log set / burn media been installed as per instructions? 5.
  • Page 17: Installation Record

    Model Number * Serial Number * Installation Address: * This information will need to be copied from the data plate, located on the inside of the appliance. Ensure this Operation Manual is left with the customer. IMPORTANT Rinnai RDV 600_700ER OM...
  • Page 18 NOTES Rinnai RDV 600_700ER OM...
  • Page 19 NOTES Rinnai RDV 600_700ER OM...
  • Page 20: Contacts

    Tel: 1300 555 545* Fax: 1300 555 655 Monday to Friday, 8.00 am to 5.00 pm EST. *Cost of a local call higher from mobile or public phones. For further information visit www.rinnai.com.au or email enquiry@rinnai.com.au innai has a Service and Spare Parts network with...
