INSTALLATION AND WIRING
The Eagle Quantum Premier (EQP) version of the Model OPECL Open Path Eclipse uses the identical installation
procedure, device location guidelines, and power supply requirements as described in the "Installation" section of
this manual. Refer to the EQP version wiring diagram for specific wiring termination guidance.
An important difference in EQP applications is that LON network cabling will be routed both in and out from the the
EQP OPECL receiver enclosure, so this requirement should be anticipated and planned for during installation.
Note that only the receiver is connected to the LON network. The transmitter is not connected to the LON and
requires wiring for operating power only.
Det‑Tronics recommends the use of shielded cable (required by ATEX) to prevent external electromagnetic
interference from affecting field devices.
For best fault isolation performance, the maximum LON wiring length should not exceed 1600 feet (500 meters).
Be sure that selected cable meets all job specifications. The use of other cable types can degrade system
operation. If necessary, consult factory for further suggested cable types.
11.3
APPENDIX H
EAGLE QUANTUM PREMIER COMPATIBLE OPECL
Table H-1—LON Maximum Cable Lengths
LON Cable
(Manufacturer and Part No.)*
Belden 8719
Belden 8471
FSI 0050-000006-00-NPLFP
Technor BFOU
Level IV, 22 AWG
Note: *Use the same type of cable in each wiring segment
between network extenders.
**Maximum wire lengths represent the linear wire distance of
LON communications wiring between network extenders.
The maximum wire lengths given in Table H-1 are based upon
the cable's physical and electrical characteristics.
IMPORTANT
IMPORTANT
IMPORTANT
Maximum Length**
Feet Meters
6,500 2,000
6,500 2,000
6,500 2,000
4,900 1,500
4,500 1,370
