INSTALLATION
Before Installation
Dimensions and Clearances
Too small of a distance from adjacent items may
result in the degradation of freezing capability and
increased electricity costs. Allow over 50 mm of
clearance between the back of the appliance and
the wall when installing the appliance.
A
B
C
-
-
Type 1
A
912
B
1793
C
933
D
808
E
878
F
933
G
1229
H
1699
NOTE
• You can determine what type of appliance it is by
looking at the label inside the appliance.
D E
F
G
H
Size (mm)
Type 2
912
1793
744
619
689
744
1039
1699
Ambient Temperature
• The appliance is designed to operate within a
limited range of ambient temperatures,
depending on the climate zone.
• The internal temperatures could be affected by
the location of the appliance, the ambient
temperature, the frequency of door opening and
so on.
• The climate class can be found on the rating
label.
Climate Class
SN (Extended
Temperate)
N (Temperate)
ST (Subtropical)
T (Tropical)
* Australia, India, Kenya
** Argentina, Ecuador
NOTE
• The appliances rated from SN to T are intended
to be used at an ambient temperature between
10 ºC and 43 ºC.
INSTALLATION
11
Ambient Temperature
Range ºC
+10 - +32
+16 - +32
+16 - +38 / +18 - +38**
+10 - +43* / +16 - +43 /
+18 - +43**
EN
